[SHIMANO] Genuine Spare Parts for 16 SUPER AERO KISU SPECIAL Fine thread specification Product Code: 035226 **Back-order (Shipping in 3-4 weeks after receiving order)

[SHIMANO] Genuine Spare Parts for 16 SUPER AERO KISU SPECIAL Fine thread specification Product Code: 035226 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.77 - US$156.31 [Regular Price: US$1.10 - US$223.30]

Prices vary according to options.

View availability
Part Number:
Quantity:
Contact Us

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.

　Reel Part's Schematic Diagram


* Circled figures indicate bearings.
* Please note disassembly is at your own risk.

No. S Part No. Description Price (USD)
*F01 13QN5 REEL BAG 22.55
1 13AXF DRAG KNOB 11.55
3 106VN SPOOL WASHER SET 1.10
4 10TQC SPOOL HOLDER (A) 1.65
5 10J01 SPOOL HOLDER (B) 1.65
6 10MGG FIXING BOLT 1.10
7 10K2Y RETAINER 1.65
8 10JPE SPOOL SHAFT BEARING SEAL 2.75
9 1080N ROTATING FRAME NUT 6.05
10 13M6X FIXING BOLT 6.05
11 10KWF SPOOL SHAFT 11.55
12 13AY3 ROTOR FLANGE 9.35
13 13AXX ARM FIXED SHAFT COLLAR 2.75
18 13AY4 LINE ROLLER BEARING COLLAR 2.75
19 10HWT LINE ROLLER BEARING COLLAR 1.65
20 13MAT FIXING BOLT 6.05
21 13AXU ARM CAM 9.35
22 10Q8D FIXING BOLT 6.05
23 10C2N COVER FIXING BOLT 2.75
24 10929 ARM CAM SPRING COVER 6.05
25 105VB ARM SPRING GUIDE (A) 1.65
26 10HDC SPRING GUIDE (A) COLLAR 1.65
27 105KW ARM CAM SPRING 1.65
28 107A1 ARM SPRING GUIDE (B) 1.65
29 13CF0 ROTOR 101.20
30 10M9V MOUNTING KECAM COVER 6.05
31 13AXW ARM FIXING SHAFT 6.05
32 13ARA BAIL ASSEMBLY 67.65
33 10D1P BALE MOUNTING KEKAM SEAT 1.65
34 10G6R BALE MOUNTING KECAM FIXING SHAFT PLATE 1.65
35 10K59 MOUNTING BOLT COLLAR 3.85
36 1073U ROTATING FRAME GUARD 9.35
37 10CYW GUARD FIXING BOLT (A) 2.75
38 107L7 INNER GERI LEVER SEAT 2.75
39 10731 WASHER 3.85
40 108M1 INNER GERI LEVER 1.65
41 10D22 INNER GERI LEVER SPRING GUIDE (B) 1.65
42 106P6 INTERNAL GERI LEVER SPRING 1.10
43 10D1Y SPRING GUIDE (A) 1.65
44 103H6 FIXING BOLT 1.65
45 10TN5 ROLLER CLUTCH COVER 17.05
46 10MLQ O-RING 3.85
47 10MGZ ROLLER CLUTCH SEAL 6.05
48 10CGX ROTATING FRAME RING 6.05
49 10L5Y ROLLER CLUTCH COVER PLATE 1.65
50 106F5 ROLLER CLUTCH PLATE 2.75
51 10QRH ROLLER CLUTCH ASSEMBLY 17.05
52 10ML3 FIXING BOLT 1.65
53 10551 BEARING PUSH PLATE 3.85
54 104PV BALL BEARING (10X19X5) 13.75
55 13L6M PINION GEAR 22.55
56 10583 BALL BEARING (8X12X3.5) 13.75
57 10MLS O RING 2.75
58 106F8 STOPPER CAM RING 1.10
59 104YQ STOPPER CAM 3.85
60 1057L CLICK SPRING 1.65
61 10F21 SPRING INTERSEAT 1.65
62 1025Y O RING 1.65
63 106GV CROSS GEAR BUSH (FRONT) 3.85
65 102LL CROSS GEAR SHAFT 9.35
66 10TQ6 STOPPER LEVER 6.05
67 10MPU FIXING BOLT 1.10
68 10BGC BALL BEARING (9X17X5) 13.75
69 13LCA MASTER GEAR 22.55
70 10HHK CROSS GEAR RECEIVING WASHER 1.10
71 107JM INTERNAL GEARS CONTACT SURFACE 1.65
72 101R2 COVER (A) 67.65
73 10PV5 SEAL (A) 2.75
74 13AYY HANDLE SHAFT FLANGE 18.15
75 10JL7 HANDLE SHAFT (LEFT HANDLE ONLY) 9.35
76 13ASQ HANDLE SHAFT FLANGE 56.10
77 10A9T HANDLE SHAFT BOLT 3.85
78 104VX BALL BEARING (4X7X2.5) 13.75
79 13AYP HANDLE KNOB 9.35
80 104FH WASHER 2.20
81 103E9 FIXING BOLT 1.10
82 13AYX HANDLE KNOB NAMEPLATE 3.85
83 103NM FIXING BOLT 2.75
84 13AT5 HANDLE ASSEMBLY 112.20
85 10ML9 FIXING BOLT 1.10
86 103GQ FIXING BOLT 1.10
87 10HCH SLIDER 6.05
88 106QY CROSS GEAR PIN 3.85
89 10RKQ WASHER 2.20
90 10JVA CROSS GEAR PIN COLLAR 2.75
91 10H7L CROSS GEAR PIN PUSH PLATE 1.10
92 10LYX FIXING BOLT 1.10
93 10GQ9 BODY GUARD (A) 9.35
94 10TNR FIXING BOLT 2.75
95 10CT7 BODY GUARD (B) 9.35
96 107CJ MAIN BODY COVER 1.65
97 103EE FIXING BOLT 2.75
98 10BF2 CROSS GEAR SHAFT COVER 3.85
99 10H44 CROSS GEAR SHAFT COVER SHEET 1.65
100 103C8 FIXING BOLT 1.10
101 1032Z SLIDER GUIDE (A) 2.75
102 104M2 SLIDER GUIDE (B) 2.75
103 10PDA BALL BEARING (3X6X2.5) 13.75
104 10J1F WASHER 1.10
115 13AYL COVER (B) 22.55
116 108WS O-RING 4X6 1.10
117 109LV LUBRICATION HOLE CAP 3.85
118 108WP O-RING 1.65
119 13AYA HANDLE SCREW CAP 13.75
120 10C2W FIXING BOLT 6.05
121 13CPM LINE ROLLER (WITH BEARING) 22.55
141 10FHS HANDLE SHAFT (RIGHT H ONLY) (ACCESSORY) 9.35
142 13K4B SAND PROTECTOR (ACCESSORY) 3.85
143 13R11 SPOOL PROTECTOR 6.05
144 10PBR LEG PROTECTOR SHEET 2.75
151 10H2S GEAR FOR CROSS GEAR 6.05
152 10CTC INTERMEDIATE GEAR SHAFT BUSH 2.75
153 13MMM INTERMEDIATE GEAR 9.35
154 10CKD INTERMEDIATE GEAR SHAFT 3.85
155 13ARJ BODY 223.30
161 13AXJ SPOOL (FOR PE NO.1) 179.30
AC02 13QTP NO. SEALS 1.65
BNKI 13B3V EXPLODED VIEW (ACCESSORY) 1.65
TRST 13PMX INSTRUCTION MANUAL (ACCESSORY) 1.65
