[SHIMANO] Genuine Spare Parts for 16 STRADIC CI4+ 4000XGM Product Code: 034953 **Back-order (Shipping in 3-4 weeks after receiving order)

[SHIMANO] Genuine Spare Parts for 16 STRADIC CI4+ 4000XGM Product Code: 034953 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.66 - US$47.19 [Regular Price: US$1.10 - US$78.65]

Prices vary according to options.

View availability
Part Number:
Quantity:
Contact Us

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.


- Genuine Spool Purchase

* If you just want the genuine spool (No.102 / Spool Unit), you can purchase it from the following link without waiting for weeks if it's in our stock now.
https://www.hedgehog-studio.co.jp/product/3101

　Reel Part's Schematic Diagram


* Circled figures indicate bearings.
* Please note disassembly is at your own risk.

No. S Part No. Description Price (USD)
4 102ZQ DRAG WASHERS 1.65
5 102XW EAR WASHERS 1.65
7 10C14 DRAG WASHERS 1.65
10 10TRB FIXING BOLT 1.65
13 10PN3 SET SCREW (M2 X 5) 1.65
20 10PME FIXING BOLT 1.10
21 10TRH RETAINER 2.75
22 107L4 ROTOR BEARING SEAL 2.75
23 10TPL ROTOR NUT 3.85
24 10GAS LINE ROLLER BEARING COLLAR 2.75
25 10DPT LINE ROLLER ASSEMBLY 22.55
26 10TRL LINE ROLLER BEARING COLLAR 2.75
27 1079V LINE ROLLER BEARING COLLARS 1.65
28 10CH0 BAIL TRIP LEVER CLICK SPRING 1.65
31 10K40 FIXING BOLT 2.75
32 10PS5 FIXING BOLT 1.65
34 10DN8 FIXING BOLT 1.10
37 1018Z WAGON 1.65
38 10TPC ARM FIXING SHAFT 6.05
39 1061L ARM SPRING GUIDE (A) 3.85
40 10TYE SPRING GUIDE (A) COLLAR 1.65
42 107AB ARM CAM SPRING SEAT 2.75
43 10TRC ARM SPRING GUIDE (A) COLLAR BUSH 1.65
47 10JHG ROTOR COLLAR 3.85
48 103C6 FIXING BOLT 1.10
49 10L62 ROLLER CLUTCH COVER PLATE 1.65
50 10MH6 ROLLER CLUTCH SEAL 3.85
51 10QPN ROLLER CLUTCH ASSEMBLY 11.55
52 10MLU O-RING 3.85
55 104JZ BALL BEARING (5X8X2.5) 13.75
56 104FV FRICTION RING 2.75
57 10TQF INNER GERI HITARI 1.65
58 10CLE INTERMEDIATE GEAR SHAFT 3.85
59 10HBH WORM SHAFT GEAR 3.85
60 104PP BALL BEARING (7X11X3) 13.75
61 10AAV DRIVE GEAR SET 22.55
62 10JDC ADJUSTMENT WASHER SET 1.10
63 104JD BALL BEARING (7X13X4) 13.75
64 10CBD COVER FLANGE SEAL 2.75
66 10LZG FIXING BOLT 1.10
67 10DNB FIXING BOLT 1.65
68 10DNC FIXING BOLT 1.65
69 10PXV HANDLE SHAFT SEAL 2.75
73 10PXZ HANDLE KNOB BUSH 1.65
74 10R38 HANDLE KNOB 17.05
75 104FH WASHER 2.20
76 104VX BALL BEARING (4X7X2.5) 13.75
77 10LFA FIXING BOLT 1.10
78 10R3A HANDLE CAP 3.85
80 10QVK FIXING BOLT 1.65
81 10L67 FIXING BOLT 1.65
82 10HAE WORM SHAFT PIN PUSH PLATE 1.65
83 10JXT WORM SHAFT PIN COLLAR 1.65
84 10RKQ WASHER 2.20
87 106RH INTERMEDIATE GEAR (SMALL) 2.75
88 10B7U WORMSHAFT PIN WASHER 1.65
89 10CNR INTERMEDIATE GEAR (LARGE) 6.05
90 106MB WORM SHAFT BUSHING 1.65
91 10PRZ FIXING BOLT 1.65
92 10DM4 BODY GUARD 11.55
93 103KW FIXING BOLT 1.10
94 10ATJ WORM SHAFT COVER 1.65
95 106CN WORM SHAFT BUSHING 1.65
98 10JAC O-RING 1.65
99 10337 SLIDER GUIDE 1.65
100 10DMF BODY 22.55
102 10N4J HANDLE SCREW CAP 11.55
104 10HEP WASHER 1.10
105 104Q5 BALL BEARING (7 X 14 X 5) 13.75
106 10CHA BAIL TRIP LEVER CLICK PIN 1.65
107 108WH O-RING 1.65
108 10ECK WASHER 1.10
109 106UZ WORM SHAFT PIN 3.85
110 105R6 ARM CAM SPRING 1.65
121 10DLW DRAG KNOB 17.05
123 10QBV OVAL WASHERS 6.05
124 10B9D DRAG KOBOLD WASHER 2.75
125 10DNN SPOOL PIN SPRING 1.65
126 10DNK SPOOL PIN 1.65
127 13CEU SPOOL ASSEMBLY 78.65
128 10BSJ SPOOL WASHER SET 1.10
129 10LWG MAIN SHAFT BEARING GUIDE 3.85
130 10J3G SPOOL BUSHING 1.65
131 107V2 RATCHET SPRING 1.65
132 107PS DRAG SOUND EMITTING RATCHET 2.75
133 103PE SPOOL RECEIVER 1.65
134 10DNV ARM CAM 6.05
135 10DN9 FIXING BOLT 1.65
137 10DNR ROTOR 28.05
138 10DMA INTERNAL GRIPPER LEVER 2.75
139 1020G BAIL ASSEMBLY 45.10
140 10DNZ BALE MOUNTING BRACKET COVER 9.35
141 10PSA FIXING BOLT 1.10
142 10C53 PINION GEAR 12.65
143 13DUL KIFTER WITH LEGS 28.05
144 10PQL HANDLE SHAFT FLANGE (B) 3.85
145 10DN5 HANDLE SHAFT FLANGE 12.65
146 101ZZ HANDLE 28.05
147 10DLJ HANDLE ASSEMBLY 62.15
148 10DMZ MAIN SHAFT ASSEMBLY 20.35
149 1068J WORM SHAFT 6.05
150 101Z1 BALANCER GUARD ASSEMBLY 9.35
151 10LA3 FIXING BOLT 1.65
152 101ZJ BALANCER (A) 2.75
153 10B8N STOPPER SPRING 1.65
BNKI 13B42 EXPLODED VIEW (ACCESSORY) 1.65
ITOS 10G4L SPOOL THREAD STOPPER SEAL (ACCESSORY) 1.65
MH01 13NFR NAMEPLATE ON THE BACK OF THE LEG 2.75
TRST 13PMK INSTRUCTION MANUAL (ACCESSORY) 1.65
