[SHIMANO] Genuine Spare Parts for 13 Stephano 200XG/201XG 200XG Product code: 031549 **Back-order (Shipping in 3-4 weeks after receiving order)

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.

Reel Part's Schematic Diagram

* Circled figures indicate bearings.
* As for the "28 / ROLLER CLUTCH", they don't sell separately.
These parts are supposed to be provided when customers send the reel to have it repaired or overhauled.
So we cannot provide you with the products unfortunately.
* Please note disassembly is at your own risk.

No.	S Part No.	Description	Price (USD)
1	13M72	HANDLE FIXING BOLT	9.35
2	10C6E	HANDLE FIXING BOLT YURUMI STOPPER	1.65
3	13UZE	STAR DRAG	6.05
5	10BT0	CLICK PIN	1.65
6	13V9F	STAR DRAG FIXING NUT	2.75
7	10J1N	STAR DRAG SPACER	1.65
8	10D60	MAIN GEAR WASHER (C)	1.65
9	107QE	HANDLE RECEIVING WASHER	1.10
10	10J20	STAR DRAG CLICK PLATE	1.65
11	10GF8	RING WASHER (A)	1.10
12	13M8Y	HANDLE CAP	4.95
13	10LAA	O-RING	1.10
14	103E9	FIXING BOLT	1.10
15	104VX	BALL BEARING (4X7X2.5)	13.75
16	104FH	WASHER	2.20
17	13E35	HANDLE KNOB	22.55
18	13HU9	HANDLE KNOB	39.60
19	13J6U	HANDLE ASSEMBLY	106.70
20	10ML5	FIXING BOLT	1.10
21	13UA5	ROLLER CLUTCH INNER TUBE	11.55
22	13VAW	RETAINER HANDLE	6.05
23	10LZD	FIXING BOLT	1.65
24	13LDP	LUBRICATION HOLE CAP	7.15
25	1085H	MECHANICAL BRAKE WASHER	1.10
26	109EB	O-RING S11.2	1.65
27	13TXN	BALL BEARING (3 X 7 X 3)	13.75
28	10F35	ROLLER CLUTCH BEARING *Cannot be ordered	17.05
29	13HKX	BODY A SET	73.15
30	10D3R	STAR DRAG PLATE	6.05
31	1071W	STAR DRAG WASHER (C)	3.85
32	13UMM	DRIVE GEAR	22.55
33	10CHZ	STAR DRAG WASHER	2.75
34	10D77	STOPPER GEAR	3.85
35	13UJF	DRIVE GEAR SHAFT	22.55
36	10JDX	SPRING FOR WORM SHAFT GEAR	1.65
38	10JAG	WORM SHAFT GEAR	2.75
39	10MT2	FIXING BOLT	1.10
40	109T0	MAIN GEAR SHAFT FIXING PLATE	2.75
41	105BP	BALL BEARING (5X9X3)	13.75
42	10C47	MAIN GEAR SHAFT WASHER	1.10
43	105NK	E TYPE STOP RING 2.5	1.10
44	10FP8	CROSS GEAR (C)	6.05
45	104ZU	CROSS GEAR SHAFT	6.05
46	10ND4	CROSS GEAR RECEIVER (A)	1.65
47	13S1X	LEVEL WINDING PIPE	6.05
48	13SLL	PINION GEAR	17.05
49	104BM	CLUTCH YOKE SPRING	1.10
50	1046S	CLUTCH YOKE	1.65
51	10LVH	CLUTCH CAM FIXING BOLT	1.10
52	10F5Z	CLUTCH CAM PUSH PLATE	3.85
53	13U56	CLUTCH CAM	2.75
54	10607	CLUTCH CLAW	3.85
55	13T04	CLUTCH CLAW SPRING	2.75
56	10NPX	CLUTCH PLATE	4.95
57	10Q7J	CLUTCH PLATE BEARING	1.65
58	10GUQ	LEVEL WINDING GUIDE	3.85
59	103C0	FIXING BOLT	1.10
60	10EX8	BALL BEARING (8X12X3.5)	13.75
61	10LV6	FIXING BOLT	1.10
62	10BW2	BODY A SEAT	3.85
63	1099P	CLUTCH LEVER RECEIVING KE (B)	1.65
64	13H27	CLUTCH LEVER	9.35
65	13S7W	LEVEL WIND GUARD	4.95
66	10FJG	LEVEL WINDING RECEIVER	1.65
67	10CFW	ADJUSTMENT WASHER SET	1.10
68	10FFX	CROSS GEAR PIN	2.75
69	10NYZ	LEVEL WINDING ASSEMBLY	22.55
70	104SS	CROSS GEAR RECEPTACLE (B)	1.65
71	10G86	ADJUSTMENT WASHER SET (B)	1.10
72	105NC	E TYPE RETAINING RING 2	1.10
73	108SK	SEAT METAL	1.10
74	108Q2	BODY FRAME CONTACT WASHER	1.10
75	108AT	FIXING PLATE FOR MAIN FRAME B	9.35
76	103EG	FIXING BOLT	1.10
77	13G1H	FRAME	123.75
78	13GRK	SPOOL ASSEMBLY	73.15
79	10GEW	BEARING PULL-OUT STOPPER	1.10
80	105C0	BALL BEARING (3X10X4)	13.75
81	1057S	SPOOL SHAFT CONTACT (B)	1.10
82	13PFJ	WASHER	1.10
83	10ML4	FIXING BOLT	1.10
84	13RQ7	FRAME B HOLDER	11.55
85	108WS	O-RING 4X6	1.10
86	13U0M	MECHANICAL BRAKE KNOB	6.05
87	10MT3	FIXING BOLT	1.10
88	10KVL	CLICK PIN FIXING PLATE	1.10
89	10K07	CLICK SPRING	1.65
90	13RJG	CLICK PIN	1.65
91	13RAD	BODY B	17.05
92	13RX2	B RECEIVER ADJUSTMENT WASHER	1.65
93	13FU2	BRAKE KNOB	11.55
94	13FQB	BODY B ASSEMBLY	56.10
95	10988	CLICK SPRING	1.65
96	10HJG	WORM SHAFT GEAR PIN	1.65
111	10PBQ	LEG PROTECTION SHEET	1.65
112	10NC0	REEL WRENCH (ACCESSORY)	1.65
113	10A61	REEL WRENCH (ACCESSORY)	3.85
BNKI	13WSG	EXPLODED VIEW (ACCESSORY)	1.65
HONT	13FQB	MAIN UNIT B SET	56.10
OIL2	10LQ1	SSRO-01 OIL (4.5G)	3.85
TRST	13VQJ	INSTRUCTION MANUAL (ACCESSORY)	1.65
