[SHIMANO] Genuine Spare Parts for 14 Scorpion 201 Product code: 032249 **Back-order (Shipping in 3-4 weeks after receiving order)

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.


- Genuine Spool Purchase

* If you just want the genuine spool (No.76 / Spool Unit), you can purchase it from the following link without waiting for weeks if it's in our stock now.
https://www.hedgehog-studio.co.jp/product/1974

Reel Part's Schematic Diagram

* Circled figures indicate bearings.
* As for the "30 / ROLLER CLUTCH" , they don't sell separately.
These parts are supposed to be provided when customers send the reel to have it repaired or overhauled.
So we cannot provide you with the products unfortunately.
* Please note disassembly is at your own risk.

No.	S Part No.	Description	Price (USD)
1	103EE	FIXING BOLT	2.75
2	10Q5Q	RETAINER	3.85
4	13MAA	HANDLE CAP	3.85
5	103E9	FIXING BOLT	1.10
6	10PXY	HANDLE GRIP BUSHING (B)	1.65
7	104FH	WASHER	2.20
9	104VX	BALL BEARING (4 X 7 X 2.5)	13.75
10	13HRE	HANDLE	22.55
12	10KXV	STAR DRAG CLICK PLATE	1.65
13	10J26	STAR DRAG CLICK PLATE	1.65
14	10BT0	CLICK PIN	1.65
15	10BT2	CLICK SPRING	1.65
17	10A70	STAR DRAG SPRING	2.75
19	10J1N	STAR DRAG SPACER	1.65
20	10D60	MAIN GEAR WASHER (C)	1.65
21	13TXR	MECHANICAL BRAKE KNOB	9.35
22	10896	MECHANICAL BRAKE WASHER	1.10
23	1085F	MECHANICAL BRAKE WASHER	1.10
25	105C0	BALL BEARING (3 X 10 X 4)	13.75
26	10EYS	BEARING SPACER	2.75
28	10MPT	FIXING BOLT	1.10
30	10F5D	ROLLER CLUTCH BEARING A-RB *Cannot be ordered	17.05
31	10CCN	INNER TUBE	6.05
32	10D3H	STAR DRAG PLATE	2.75
33	106XT	STAR DRAG WASHER	6.05
35	10CHF	STAR DRAG WASHER	6.05
36	109BB	STOPPER GEAR	6.05
38	10HJG	WORM SHAFT GEAR PINS	1.65
39	10J47	WORM SHAFT GEAR	2.75
40	10MT0	FIXING BOLT	1.10
41	109T0	MAIN GEAR SHAFT FIXING PLATE	2.75
42	10C47	MAIN GEAR SHAFT WASHER	1.10
43	105NK	E TYPE RETAINING RING 2.5	1.10
45	10FJB	LEVEL WINDING RECEIVER	1.65
46	10CFW	ADJUSTMENT WASHER SET	1.10
47	10FFZ	WORM SHAFT PIN	2.75
48	108WQ	O-RING	1.65
49	10NVQ	LEVEL WINDING ASSEMBLY	11.55
50	10FNV	WORM SHAFT GEAR	2.75
51	10AEZ	WORM SHAFT PIN	1.10
52	104SN	WORM SHAFT	6.05
53	10NFQ	LEVEL WINDING PIPE	1.65
54	103DC	FIXING BOLT	1.10
56	10487	CLUTCH YOKE SPRING	1.10
58	10LVE	FIXING BOLT	1.10
59	10F3X	CLUTCH CAM PUSH PLATE	3.85
64	103C0	FIXING BOLT	1.10
65	10EX8	BALL BEARING (8 X 12 X 3.5)	13.75
67	105NB	E TYPE STOP RING 1.5	1.10
71	10QSE	LEVEL WINDING GUIDE	1.65
72	10FJZ	WASHER	1.10
73	105NC	E TYPE RETAINING RING 2	1.10
74	108SK	WASHER	1.10
75	108PY	FRAME ATTACHMENT WASHER	1.65
76	13GHJ	SPOOL ASSEMBLY	56.10
77	1046G	BRAKE SHOE (M) RED	1.10
78	10GEW	BEARING RETAINING CLAMP	1.10
79	1057S	SPOOL SHAFT CONTACT (B)	1.10
80	10EXQ	BRAKE PIPE GEAR	13.75
81	103N4	FIXING BOLT	1.10
83	104MZ	BODY B CAM LEVER ADJUSTMENT WASHER	1.65
85	10KNG	DAMPER SPRING	1.10
86	103LE	FIXING BOLT	1.10
87	10GFB	CAM LEVER ADJUSTMENT WASHER	1.10
89	103L7	FIXING BOLT	1.10
90	10CLF	INTERMEDIATE GEAR	1.65
92	105BP	BALL BEARING (5 X 9 X 3)	13.75
93	10JDY	WORM SHAFT GEAR SPRING	1.65
94	10TMT	MECHANICAL BRAKE YURUMI STOP SPRING	1.65
95	10LCT	FIXING BOLT	1.65
141	10FFD	HANDLE FIXING NUT	2.75
142	13UZZ	HANDLE KNOB	11.55
143	13HY7	HANDLE ASSEMBLY	67.65
144	10AU0	STAR DRAG	17.05
145	10A3U	STAR DRAG FIXING NUT	3.85
146	13TQV	BODY A	22.55
147	10CMF	DRIVE GEAR	22.55
148	1058M	DRIVE GEAR SHAFT	11.55
149	13S6W	LEVEL WINDING GUARD	6.05
150	10CRZ	PINION GEAR	11.55
151	1046W	CLUTCH YOKE	1.65
152	10K0P	CLUTCH CAM	2.75
153	10MQM	CLUTCH CLAW	3.85
154	10QGJ	CLUTCH PLATE	4.95
155	10BVM	BODY A SEAT	3.85
156	13FWW	FRAME	50.60
157	1096T	CLUTCH LEVER RECEIVER (B)	1.65
158	10CDM	CLUTCH LEVER	6.05
159	10FXC	FRAME B RECEIVER ASSEMBLY	13.75
160	10BAL	BODY B CAM LEVER	2.75
161	10AZC	BR KNOB	3.85
162	13R3N	BODY B ASSEMBLY	11.55
163	104CQ	CLUTCH CLAW SPRING	1.65
BNKI	13WKD	EXPLODED VIEW (ACCESSORIES)	1.65
OIL1	10LQ0	B-100 OIL (4.5G)	3.85
TRST	13VN4	INSTRUCTION MANUAL (ACCESSORY)	1.65
