[SHIMANO] Genuine Spare Parts for 22 CURADO DC 201HG Product code: 045027 **Back-order (Shipping in 3-4 weeks after receiving order)

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.


- Genuine Spool Purchase

* If you just want the genuine spool (No.80 / Spool Unit), you can purchase it from the following link without waiting for weeks if it's in our stock now.
https://www.hedgehog-studio.co.jp/product/5617

Reel Part's Schematic Diagram

* Circled figures indicate bearings.
* As for the "29 / ROLLER CLUTCH", they don't sell separately.
These parts are supposed to be provided when customers send the reel to have it repaired or overhauled.
So we cannot provide you with the products unfortunately.
* Please note disassembly is at your own risk.

No.	S Part No.	Description	Price (USD)
1	10DV5	FIXING BOLT	1.10
2	10SSK	RETAINER	3.85
4	10SS2	HANDLE CAP	1.10
5	10LFA	FIXING BOLT	1.10
6	10PXZ	HANDLE KNOB BUSH	1.65
7	104FH	WASHER	2.20
9	10KXW	STAR DRAG CLICK PLATE RETAINER	1.65
10	10J26	STAR DRAG CLICK PLATE	1.65
11	10MFC	CLICK PIN	1.65
12	10BT2	CLICK SPRING	1.65
14	10A70	STAR DRAG SPRING	2.75
16	10J1N	STAR DRAG SPACER	1.65
17	109F5	DRIVE GEAR WASHER	1.65
18	100SE	WASHER	1.10
19	10EX8	BALL BEARING (8 X 12 X 3.5)	13.75
20	10SRP	MECHANICAL BRAKE KNOB	9.35
21	10896	MECHANICAL BRAKE WASHER	1.10
22	1085F	MECHANICAL BRAKE WASHER	1.10
23	1054D	BEARING PULL-OUT STOPPER	1.10
24	105C3	BALL BEARING (3 X 10 X 4)	7.15
25	10EYS	BEARING SPACER	2.75
26	105BP	BALL BEARING (5 X 9 X 3)	13.75
27	108WK	O-RING SM14	1.65
29	1005E	ROLLER CLUTCH *Cannot be ordered	17.05
30	10SRM	ROLLER CLUTCH INNER TUBE	6.05
31	10SSR	STAR DRAG PLATE	2.75
32	10SSF	STAR DRAG WASHER	11.55
34	1023U	STAR DRAG WASHER	6.05
35	10SSJ	STOPPER GEAR	6.05
37	10JDY	SPRING FOR WORM SHAFT GEAR	1.65
38	10HJG	WORM SHAFT GEAR PINS	1.65
39	101K8	WORM SHAFT GEAR	3.85
40	10S3Y	FIXING BOLT	1.10
41	109T1	DRIVE GEAR SHAFT FIXING PLATE	2.75
42	10G6D	WASHER	1.65
43	105NK	E TYPE STOPPER RING 2.5	1.10
45	10FJB	LEVEL WINDING RECEIVING PLATE	1.65
46	10CFU	WORM SHAFT PIN	1.10
47	10BHQ	WORM SHAFT PIN	2.75
48	108WQ	O-RING	1.65
49	101E0	LEVEL WINDING ASSEMBLY	11.55
50	10SRL	WORM SHAFT GEAR	3.85
51	101JU	WORM SHAFT	1.10
52	101JR	LEVEL WINDING PIPE	1.10
53	101GT	O-RING	1.65
55	10SAS	CLUTCH YOKE SPRING	1.10
57	10F3X	CLUTCH CAM PUSH PLATE	3.85
58	10LVE	FIXING BOLT	1.10
63	10559	FIXING BOLT	1.65
64	10190	WASHER	1.65
65	10S57	FIXING BOLT	1.65
70	10LCQ	FIXING BOLT	1.10
71	10MPD	FIXING BOLT	1.10
73	10SXB	FIXING BOLT	1.65
74	101JX	LEVEL WINDING GUIDE	1.65
75	10FJZ	WASHER	1.10
76	105NC	E TYPE RETAINING RING 2	1.10
77	10LHY	FIXING BOLT	1.65
78	10SXA	FIXING BOLT	1.65
79	10MD0	SPOOL CLUTCH PIN	1.65
80	101MG	SPOOL ASSEMBLY	99.55
81	10TBS	FIXING BOLT	1.65
82	10LFN	FIXING BOLT	1.10
83	100MF	WASHER	2.75
84	101JZ	BODY B SUBSTRATE ASSEMBLY	123.42
85	10T9T	WASHER	1.10
87	10GQZ	CLICK SPRING	1.10
89	10B94	BEARING SEAL	1.65
90	100Q2	BEARING STOPPER	2.75
91	10EX5	SPOOL SHAFT CONTACT B	1.10
92	100Q5	SPOOL SHAFT CONTACT C	1.65
301	10T0Z	HANDLE FIXING NUT	2.75
302	10U0Q	HANDLE ASSEMBLY	22.55
303	10TB5	STAR DRAG	15.95
304	10A3U	STAR DRAG FIXING NUT	3.85
307	10EBF	DRIVE GEAR SHAFT	11.55
308	1019X	LEVEL WINDING GUARD	2.75
311	10EB3	CLUTCH CAM	2.75
312	1003W	CLUTCH CLAW ASSEMBLY	3.85
313	104CQ	CLUTCH CLAW SPRING	1.65
314	1019Y	CLUTCH PLATE	2.75
315	10EBG	BODY A SEAT	3.85
316	10EBK	CLUTCH BAR GUIDE (B)	1.65
317	10TKF	CLUTCH LEVER	7.15
318	10EB4	CLUTCH LEVER SEAT (A)	1.65
319	10RA7	FRAME ASSEMBLY	44.00
320	100E5	BRAKE DIAL	10.45
321	100YQ	CLICK SHILLING	1.65
322	10TB4	BODY B	7.15
323	10TKC	BODY B ASSEMBLY	165.00
401	1002U	BODY A	20.35
402	10EB5	DRIVE GEAR	22.55
403	10EB9	PINION GEAR	11.55
404	1046W	CLUTCH YOKE	1.65
PUNT	13X9P	INSTRUCTION MANUAL EXPLODED VIEW SET (ACCESSORIES)	2.20
