[SHIMANO] Genuine Spare Parts for 15 CITICA 201 Product code: 034519 **Back-order (Shipping in 3-4 weeks after receiving order)

[SHIMANO] Genuine Spare Parts for 15 CITICA 201 Product code: 034519 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.77 - US$35.42 [Regular Price: US$1.10 - US$50.60]

Prices vary according to options.

Not available
Contact Us

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.

　Reel Part's Schematic Diagram


* Circled figures indicate bearings.
* Please note disassembly is at your own risk.

No. S Part No. Description Price (USD)
1 103ED FIXING BOLT 1.10
2 10Q5Q RETAINER 3.85
5 10KXV STOPPER FOR STAR DRAG CLICK PLATE RETAINER 1.65
6 10J26 STAR DRAG CLICK PLATE 1.65
7 10BT0 CLICK PIN 1.65
8 10BT2 CLICK SPRING 1.65
10 10A70 STAR DRAG SPRING 2.75
12 10J1N STAR DRAG SPACER 1.65
13 10D60 MAIN GEAR WASHER (C) 1.65
14 10KDM MECHANICAL BRAKE KNOB 9.35
15 10896 MECHANICAL BRAKE WASHER 1.10
16 1085F MECHANICAL BRAKE WASHER 1.10
18 105C3 BALL BEARING (3 X 10 X 4) 7.15
19 10EYS BEARING SPACER 2.75
20 105BL BALL BEARING (5 X 9 X 3) 7.15
22 10MPT FIXING BOLT 1.10
23 10F5C ROLLER CLUTCH BEARING 17.05
24 10BMW ROLLER CLUTCH INNER TUBE 6.05
25 10D3H STAR DRAG PLATE 2.75
26 106XT STAR DRAG WASHER 6.05
28 10CHF STAR DRAG WASHER 6.05
29 109BB STOPPER GEAR 6.05
31 10JDX SPRING FOR WORM SHAFT GEAR 1.65
32 10HJG WORM SHAFT GEAR PINS 1.65
33 10J47 WORM SHAFT GEAR 2.75
34 10MT0 FIXING BOLT 1.10
35 109T0 MAIN GEAR SHAFT FIXING PLATE 2.75
36 10C47 MAIN GEAR SHAFT WASHER 1.10
37 105NK E TYPE RETAINING RING 2.5 1.10
39 10FJB LEVEL WINDING RECEIVER 1.65
40 10CFW ADJUSTMENT WASHER SET 1.10
41 10FFZ WORM SHAFT PIN 2.75
42 108WQ O-RING 1.65
43 10NVR LEVEL WINDING ASSEMBLY 9.35
44 103DC FIXING BOLT 1.10
45 105NB E TYPE STOP RING 1.5 1.10
46 10FNV WORM SHAFT GEAR 2.75
47 10PXY HANDLE GRIPPED BUSH (B) 1.65
48 10AEZ WORM SHAFT PIN 1.10
49 104SN WORM SHAFT 6.05
50 10NFQ LEVEL-WIND PIPE 1.65
52 10487 CLUTCH YOKE SPRING 1.10
54 10F3X CLUTCH CAM PUSH PLATE 3.85
55 10LVE FIXING BOLT 1.10
58 104CQ CLUTCH CLAW SPRING 1.65
60 103C0 FIXING BOLT 1.10
61 10EX6 BALL BEARING (8 X 12 X 3.5) 7.15
66 10QSE LEVEL WINDING GUIDE 1.65
67 10FJZ WASHER 1.10
68 105NC E TYPE STOP RING 2 1.10
69 108SK WASHER 1.10
70 108PY FRAME ATTACHMENT WASHER 1.65
71 10L13 SPOOL ASSEMBLY 50.60
72 1046G BRAKE SHOE (M) RED 1.10
73 10GEW BEARING RETAINING CLAMP 1.10
74 1057S SPOOL SHAFT CONTACT (B) 1.10
75 10EXQ BRAKE PIPE GEAR 13.75
76 103N4 FIXING BOLT 1.10
77 10F0N FRAME B RECEIVER ASSEMBLY 13.75
78 104MX BODY B CAM LEVER ADJUSTMENT WASHER 1.65
80 10KNG DAMPER SPRING 1.10
81 103LE FIXING BOLT 1.10
82 10GFB CAM LEVER ADJUSTMENT WASHER 1.10
84 103L7 FIXING BOLT 1.10
85 10CLF INTERMEDIATE GEAR 1.65
86 10GQZ CLICK SPRING 1.10
88 10TMT MECHANICAL BRAKE LOOSENING STOP SPRING 1.65
89 10LCT FIXING BOLT 1.65
121 10FFE HANDLE FIXING NUT 2.75
122 10CF0 HANDLE ASSEMBLY 50.60
123 10AU0 STAR DRAG 17.05
124 10A3U STAR DRAG FIXING NUT 3.85
125 10GK7 BODY A 22.55
126 10CMF DRIVE GEAR 22.55
127 1058M DRIVE GEAR SHAFT 11.55
128 10FWF LEVEL WINDING GUARD 6.05
129 10CRZ PINION GEAR 11.55
130 1046W CLUTCH YOKE 1.65
131 10K0P CLUTCH CAM 2.75
132 10MQM CLUTCH CLAW 3.85
133 10QGJ CLUTCH PLATE 4.95
134 10BVM BODY A SEAT 3.85
135 10EVF FRAME 45.10
136 1096T CLUTCH BAR GUIDE (B) 1.65
137 10CDM CLUTCH LEVER 6.05
138 10BAL BODY B CAM LEVER 2.75
139 10AZC BR KNOB 3.85
140 10D0C BODY B 11.55
BNKI 13WKL EXPLODED VIEW (ACCESSORIES) 1.65
OIL1 10LQ0 B-100 OIL (4.5G) 3.85
TRST 13VJ0 INSTRUCTION MANUAL (ACCESSORY) 1.65
