19 SPHEROS SW 3000XG, 4000HG, 4000XG for the line roller 1BB specification tuning kit

Product concept

※ selling product is tuning kit, you are not in the reel body.
※ When you select the type of bearing, you will see each of the selling price.




With an emphasis on rotational performance, high sensitivity bearing of the tournament specifications.


It was adopted strong new material to corrosion, salt water corresponding bearing, which boasts the best of anti-rust and durability performance.

(Bearing of choice)
SHG premium bearing the light lure of freshwater fish and high-sensitivity-oriented, such as trout bus. The all saltwater fish in Salt General is recommended HRCB anti-rust bearings. ※ SHG is also salt can be used but, HRCB if to emphasize the durability is the best.

MAXBB full bearing tuning kit, can be added to BB from commercially available state until the maximum mounting number, "of dedicated bearing dedicated parts such-Manual" is a tuning kit which is full set. Recommended for beginners! We will send to align all the necessary things. ※ simple tool such as a screwdriver or pliers Please prepare.



The contents of the tuning kit

(Tuning menu)
・line roller 1BB specification bearings tune

(contents)
・line BB × 1 pcs roller (SHG-740ZZ Or HRCB-740ZHi)
・roller bush (for 1BB) × 1 or
・roller washer ( 0.8mm) 2 pieces ×
・installation instructions



Tuning menu

■ line roller 1BB specification bearings tune



because the line roller is genuine when the bearing is not included even one, it is possible to the line roller of 1BB specifications newly added one of the bearing.
(19 Suferosu SW is, because it is not possible to put two bearings to structurally line roller, will be the only 1BB specification.)

Because the rotation of the line roller is improved twist will be less likely to occur, suppleness of yarn is maintained, also improves durability and distance.


[Mounting method]

the ※ 16 Nasuki we do the commentary as an example.



First, to decompose and remove the screws that secure the line roller portion.




Photo top of the parts will be genuine. Replace the parts that came with the parts surrounded by a red frame in the kit perform again mounting.




First, it fits the bearing in the kit of the roller bush.




It includes the subsequently assembled earlier parts into the line roller body.
In this case, please attention to the direction of incorporating of each part.




Attach the line roller body incorporating the parts to the reel.
Also at this time, please pay attention to the orientation of the parts.




If there is no problem it can be installed as shown in the photograph.




Attach the white plastic of genuine ring to the portion of the arrow.




Overlapping the metal washer two pieces of kit, and built-in to the part of the photo of the arrow (the inside of the line roller body).




Install the genuine spacer of metal to the arrow portion of the reel body.




Finally, causing the arm so that each part is not falling apart, it is the work completed by performing the re-fixed with screws. Please confirm whether or not the last in the line roller is properly rotated. Please check whether the built-in neat each part disassembled again if you do not properly rotated.



Compatible models



※ The photograph is 4000XG number

Shimano 19 SPHEROS SW
(3000XG, 4000HG, 4000XG)
