[SHIMANO] Genuine Spare Parts for 16 Scorpion 71 HG Product code: 034731 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.77 [Regular Price: US$1.10]

Prices vary according to options.

View availability

Part Number:

Quantity:

Item Description

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.

- We don't accept order cancellations, changes, or refunds after an order unless the products you ordered are not available because SHIMANO/DAIWA Japan doesn't accept our cancellations.

*Please make sure to read about the conditions before you order.

　Reel Part's Schematic Diagram

* Circled figures indicate bearings.
* As for the "BSS1 /BRAKE SHOE S" and "BST1 /BRAKE SHAFT", they don't sell separately.
These parts are supposed to be provided when customers send the reel to have it repaired or overhauled.
So we cannot provide you with the products unfortunately.
* Please note disassembly is at your own risk.

No.	S Part No.	Description	Price (USD)
1	10LFC	FIXING BOLT	1.65
2	10Q5T	RETAINER	3.85
4	10TNJ	HANDLE CAP	3.85
5	103E9	FIXING BOLT	1.10
6	10PXZ	HANDLE KNOB BUSH	1.65
7	104FH	WASHER	2.20
9	104VX	BALL BEARING (4X7X2.5)	13.75
10	13HUU	HANDLE	45.10
11	13J1Z	HANDLE ASSEMBLY	90.20
12	10KXW	STAR DRAG CLICK PLATE RETAINER	1.65
13	10R3K	STAR DRAG CLICK PLATE	1.65
14	10MFC	CLICK PIN	1.65
15	10BT2	CLICK SPRING	1.65
16	10R0K	STAR DRAG	17.05
17	10A70	STAR DRAG SPRING	2.75
19	10J1N	STAR DRAG SPACER	1.65
20	13B6N	MECHANICAL BRAKE KNOB	9.35
21	10896	MECHANICAL BRAKE WASHER	1.10
22	1085F	MECHANICAL BRAKE WASHER	1.10
23	1054D	BEARING STOPPER	1.10
24	105C0	BALL BEARING (3 X 10 X 4)	13.75
25	10EYS	BEARING SPACER	2.75
26	105BP	BALL BEARING (5X9X3)	13.75
27	10R22	O-RING	1.65
29	10LCG	FIXING BOLT	1.10
30	10LCV	MAIN UNIT FIXING BOLT	1.10
31	10F5D	ROLLER CLUTCH BEARING A-RB	17.05
32	10R05	ROLLER CLUTCH INNER TUBE	6.05
33	10HJH	OVAL WASHER SPACER	1.65
34	10R0F	STAR DRAG PLATE	2.75
35	106XT	STAR DRAG WASHER	6.05
37	10CHF	STAR DRAG WASHER	6.05
38	10D73	STOPPER GEAR	6.05
40	10JDY	SPRING FOR WORM SHAFT GEAR	1.65
41	10HJG	WORM SHAFT GEAR PINS	1.65
42	10J47	WORM SHAFT GEAR	2.75
43	10LCQ	FIXING BOLT	1.10
44	109T1	DRIVE GEAR SHAFT FIXING PLATE	2.75
45	10C47	MAIN GEAR SHAFT WASHER	1.10
46	105NK	E TYPE STOP RING 2.5	1.10
48	10FJB	LEVEL WINDING RECEIVER	1.65
49	104TX	WASHER	1.10
51	108WQ	O-RING	1.65
52	10NVQ	LEVEL WINDING ASSEMBLY	11.55
53	10LFK	FIXING BOLT	1.10
54	10FNV	WORM SHAFT GEAR	2.75
55	10AEZ	WORM SHAFT PIN	1.10
57	10R10	LEVEL-WIND PIPE	1.65
59	10487	CLUTCH YOKE SPRING	1.10
61	10F3X	CLUTCH CAM PUSH PLATE	3.85
62	10LVE	FIXING BOLT	1.10
67	103C0	FIXING BOLT	1.10
68	10EX8	BALL BEARING (8X12X3.5)	13.75
73	10QSH	LEVEL-WIND GUIDE	1.65
74	10FJZ	WASHER	1.10
75	105NC	E TYPE STOP RING 2	1.10
77	10BGR	BODY B CAM LEVER PUSH PLATE	1.65
78	10MPD	FIXING BOLT	1.10
79	13GNM	SPOOL ASSEMBLY	56.10
80	10EX5	SPOOL SHAFT CONTACT B	1.10
82	10LA8	O RING	1.65
83	10L1Q	FIXING BOLT	1.10
86	10GFC	WASHER	1.65
87	10R3V	SPACER	1.65
88	10R1S	FIXING BOLT	1.65
89	10R0U	B RECEIVING AND ADJUSTING WASHER	1.65
92	10TPT	WORM SHAFT PIN	2.75
93	10TPP	WORM SHAFT	6.05
94	101Z6	BRAKE PIPE GEAR	9.35
95	10328	HANDLE KNOB	11.55
131	10FFD	HANDLE FIXING NUT	2.75
132	10A3U	STAR DRAG FIXING NUT	3.85
135	10TMV	DRIVE GEAR SHAFT	11.55
136	13B5T	LEVEL WINDING GUARD	6.05
138	1046W	CLUTCH YOKE	1.65
139	10K0P	CLUTCH CAM	2.75
140	10MQM	CLUTCH CLAW	3.85
141	10TMC	CLUTCH CLAW SPRING	1.65
142	10TME	CLUTCH PLATE	4.95
143	10TMU	BODY A SEAT	3.85
144	13FXS	FRAME	50.60
145	10TMF	CLUTCH LEVER RECEIVER (B)	1.65
146	10TMD	CLUTCH LEVER	6.05
147	1019C	BODY B CAM LEVER	2.75
148	10DLR	FRAME B RECEIVER ASSEMBLY	13.75
149	10B1Y	BR KNOB	3.85
150	13B4C	BODY B	11.55
151	13ATW	BODY B ASSEMBLY (WITH BEARINGS)	56.10
171	13HCJ	BODY A	22.55
172	10CME	DRIVE GEAR	22.55
173	10CRY	PINION GEAR	11.55
BSS1	13B5A	BRAKE SHOE S *Cannot be ordered	1.10
BST1	13SFU	BRAKE SHAFT *Cannot be ordered	1.10
