[SHIMANO] Genuine Spare Parts for 13-16 BIOMASTER SW 10000HG Product Code: 031631 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.77 [Regular Price: US$1.10]

Prices vary according to options.

View availability

Part Number:

Quantity:

Item Description

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.

*Please make sure to read about the conditions before you order.

　Reel Part's Schematic Diagram

* Circled figures indicate bearings.
* Please note disassembly is at your own risk.

No.	S Part No.	Description	Price (USD)
*F01	13QN6	REEL BAG	6.05
1	102B1	DRAG KNOB ASSEMBLY	11.55
2	10B6A	STOPPER SPRING	1.65
3	10N26	OVAL WASHER	1.10
4	10C16	DRAG WASHER	9.35
5	10BE3	DRAG EAR WASHER	1.10
6	1031M	DRAG WASHER	9.35
7	1038D	SPOOL PINS	1.65
8	10PH3	SPOOL PIN SPRING	1.65
9	10PH5	FIXING BOLT	1.65
11	10BXK	SPOOL WASHER SET	1.10
12	103PG	SPOOL HOLDER (A)	1.65
13	10J03	SPOOL HOLDER (B)	1.65
14	10L4L	MAIN SHAFT	9.35
15	103L6	FIXING BOLT	1.10
16	10MSW	ROTATING FRAME NUT	1.65
17	10GAP	ARM ROLLER BEARING COLLAR	1.65
18	10CZA	ARM ROLLER COLLAR	1.65
19	10KQS	ARM ROLLER	6.05
20	107R2	ARM ROLLER BUSH	1.65
21	105BP	BALL BEARING (5 X 9 X 3)	13.75
22	10GA3	LINE ROLLER WASHER	1.10
23	1079W	LINE ROLLER RECEIVER	1.10
24	1077Q	BAIL TRIP LEVER CLICK SPRING	1.65
25	10CH9	BAIL TRIP LEVER CLICK PIN	1.65
26	105LV	ARM SPRING GUIDE (A)	1.65
27	10TYE	SPRING GUIDE (A) COLLAR	1.65
28	10FVF	ARM CAM SPRING	1.65
29	10FAY	INTERNAL GERI LEVER	2.75
30	107X8	ARM ROLLER LUBRICATION HOLE CAP	1.65
31	1079K	ARM CAM	6.05
32	103HN	FIXING BOLT	1.65
33	103UT	FIXING BOLT	1.10
34	103DC	FIXING BOLT	1.10
35	103NP	FIXING BOLT	1.10
36	10CT2	ARM CAM SPRING COVER	6.05
37	102SM	ROTOR	34.10
38	107WL	BALE MOUNTING BRACKET COVER	6.05
39	10PZ7	ARM FIXING SHAFT	6.05
40	106LP	BAIL ASSEMBLY	22.55
41	10PFB	FIXING BOLT COLLAR	1.65
42	10HB3	BALE MOUNTING CAM SEAT	1.65
43	10FV2	FIXING SHAFT FOR MOUNTING BALE CAM	3.85
44	103LA	FIXING BOLT	1.10
45	10QNW	ROLLER CLUTCH ASSEMBLY	11.55
46	10BGD	BALL BEARING (9X17X5)	13.75
47	109PD	ADJUSTMENT WASHER	1.65
48	105WF	PINION GEAR	11.55
49	104PP	BALL BEARING (7X11X3)	13.75
50	10D7N	FRICTION RING	3.85
51	10MPW	FIXING BOLT	1.10
52	107JL	INNER GERI HITARI	1.65
53	10DBQ	STOPPER CAM	2.75
54	10DCT	CLICK SPRING	1.65
55	10ANM	STOPPER LEVER	2.75
56	10LVM	FIXING BOLT	1.10
57	10J0N	STOPPER LEVER COVER	2.75
58	106JK	CROSS GEAR BUSH (FRONT)	1.65
59	1069D	WORM SHAFT GEAR	6.05
60	104PT	BALL BEARING (8X14X4)	13.75
61	109FN	DRIVE GEAR	45.10
62	10HHU	SLIDER WASHER	1.10
63	10LSD	FIXING BOLT	1.10
65	10MBG	FIXING BOLT	1.10
66	10L26	FIXING BOLT	1.10
67	105N8	FIXING NUT	1.65
68	10MBP	FIXING BOLT	1.10
69	104KN	LUBRICATION HOLE CAP	3.85
70	10MBT	FIXING BOLT	1.10
71	106SM	HANDLE	34.10
72	10HV3	WASHER	1.10
73	104UJ	HANDLE GRIP BUSH (B)	1.65
74	1040N	HANDLE KNOB	39.60
75	10KX2	BALL BEARING (4X9X4)	13.75
76	103E9	FIXING BOLT	1.10
77	10B97	HANDLE CAP	2.75
78	108SM	HANDLE GRIP NAMEPLATE	2.75
79	103NH	FIXING BOLT	1.10
80	10HNR	HANDLE ASSEMBLY	90.20
81	10MT4	FIXING BOLT	1.10
82	10H7R	CROSS GEAR PIN PUSH PLATE	1.65
83	10RKQ	WASHER	2.20
84	10JYC	CROSS GEAR PIN COLLAR	1.65
85	106V5	CROSS GEAR PIN	6.05
86	104WE	SLIDER	8.25
87	1080B	FIXING BOLT	1.10
88	10MHE	FIXING BOLT	1.10
89	10NEE	BODY GUARD	9.35
90	10QG5	FIXING BOLT	1.10
91	103KS	FIXING BOLT	1.10
92	10AJH	CROSS GEAR SHAFT COVER	1.65
93	106EH	CROSS GEAR BUSH (REAR)	1.65
94	1059T	WASHER	1.10
95	106HX	CROSS GEAR SHAFT	6.05
96	10H18	SLIDER GUIDE	1.65
97	10B0M	LEGLESS CIBODY	22.55
98	10N18	HANDLE SCREW CAP	11.55
131	10HS1	SPOOL ASSEMBLY	67.65
132	102V5	KIFTER WITH LEGS	34.10
BNKI	13QZS	EXPLODED VIEW (ACCESSORIES)	2.75
ITOS	13QPZ	STOPPER SEAL	1.65
MH01	13NAV	NAMEPLATE ON THE BACK OF THE LEG	2.75
TRST	13PMG	INSTRUCTION MANUAL (ACCESSORY)	1.65
