[SHIMANO] Genuine Spare Parts for 16 SUPER AERO KISU SPECIAL CE ultrafine specification Product Code: 035233 **Back-order (Shipping in 3-4 weeks after receiving order)
Our Selling Price: US$0.77 [Regular Price: US$1.10]
Prices vary according to options.
Item Description
ATTENTION:
- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.
- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.
*Please make sure to read about the conditions before you order.
Reel Part's Schematic Diagram |
* Circled figures indicate bearings.
* Please note disassembly is at your own risk.
No. | S Part No. | Description | Price (USD) |
*F01 | 13QN5 | REEL BAG | 22.55 |
1 | 13AXF | DRAG KNOB | 11.55 |
2 | 13AXK | SPOOL (FOR PE 0.8) | 179.30 |
3 | 106VN | SPOOL WASHER SET | 1.10 |
4 | 10TQC | SPOOL HOLDER (A) | 1.65 |
5 | 10J01 | SPOOL HOLDER (B) | 1.65 |
6 | 10MGG | FIXING BOLT | 1.10 |
7 | 10K2Y | RETAINER | 1.65 |
8 | 10JPE | SPOOL SHAFT BEARING SEAL | 2.75 |
9 | 1080N | ROTATING FRAME NUT | 6.05 |
10 | 13M6X | FIXING BOLT | 6.05 |
11 | 10KWF | SPOOL SHAFT | 11.55 |
12 | 13AY3 | ROTOR FLANGE | 9.35 |
13 | 13AXX | ARM FIXED SHAFT COLLAR | 2.75 |
18 | 13AY4 | LINE ROLLER BEARING COLLAR | 2.75 |
19 | 10HWT | LINE ROLLER BEARING COLLAR | 1.65 |
20 | 13MAT | FIXING BOLT | 6.05 |
21 | 13AXU | ARM CAM | 9.35 |
22 | 10Q8D | FIXING BOLT | 6.05 |
23 | 10C2N | COVER FIXING BOLT | 2.75 |
24 | 10929 | ARM CAM SPRING COVER | 6.05 |
25 | 105VB | ARM SPRING GUIDE (A) | 1.65 |
26 | 10HDC | SPRING GUIDE (A) COLLAR | 1.65 |
27 | 105KW | ARM CAM SPRING | 1.65 |
28 | 107A1 | ARM SPRING GUIDE (B) | 1.65 |
29 | 13CF0 | ROTOR | 101.20 |
30 | 10M9V | MOUNTING KECAM COVER | 6.05 |
31 | 13AXW | ARM FIXING SHAFT | 6.05 |
32 | 13ARA | BAIL ASSEMBLY | 67.65 |
33 | 10D1P | BALE MOUNTING KEKAM SEAT | 1.65 |
34 | 10G6R | BALE MOUNTING KECAM FIXING SHAFT PLATE | 1.65 |
35 | 10K59 | MOUNTING BOLT COLLAR | 3.85 |
36 | 1073U | ROTATING FRAME GUARD | 9.35 |
37 | 10CYW | GUARD FIXING BOLT (A) | 2.75 |
38 | 107L7 | INNER GERI LEVER SEAT | 2.75 |
39 | 10731 | WASHER | 3.85 |
40 | 108M1 | INNER GERI LEVER | 1.65 |
41 | 10D22 | INNER GERI LEVER SPRING GUIDE (B) | 1.65 |
42 | 106P6 | INTERNAL GERI LEVER SPRING | 1.10 |
43 | 10D1Y | SPRING GUIDE (A) | 1.65 |
44 | 103H6 | FIXING BOLT | 1.65 |
45 | 10TN5 | ROLLER CLUTCH COVER | 17.05 |
46 | 10MLQ | O-RING | 3.85 |
47 | 10MGZ | ROLLER CLUTCH SEAL | 6.05 |
48 | 10CGX | ROTATING FRAME RING | 6.05 |
49 | 10L5Y | ROLLER CLUTCH COVER PLATE | 1.65 |
50 | 106F5 | ROLLER CLUTCH PLATE | 2.75 |
51 | 10QRH | ROLLER CLUTCH ASSEMBLY | 17.05 |
52 | 10ML3 | FIXING BOLT | 1.65 |
53 | 10551 | BEARING PUSH PLATE | 3.85 |
54 | 104PV | BALL BEARING (10X19X5) | 13.75 |
55 | 13L6M | PINION GEAR | 22.55 |
56 | 10583 | BALL BEARING (8X12X3.5) | 13.75 |
57 | 10MLS | O RING | 2.75 |
58 | 106F8 | STOPPER CAM RING | 1.10 |
59 | 104YQ | STOPPER CAM | 3.85 |
60 | 1057L | CLICK SPRING | 1.65 |
61 | 10F21 | SPRING INTERSEAT | 1.65 |
62 | 1025Y | O RING | 1.65 |
63 | 106GV | CROSS GEAR BUSH (FRONT) | 3.85 |
64 | 10H9L | WORM SHAFT GEAR | 6.05 |
65 | 102LL | CROSS GEAR SHAFT | 9.35 |
66 | 10TQ6 | STOPPER LEVER | 6.05 |
67 | 10MPU | FIXING BOLT | 1.10 |
68 | 10BGC | BALL BEARING (9X17X5) | 13.75 |
69 | 13LCA | MASTER GEAR | 22.55 |
70 | 10HHK | CROSS GEAR RECEIVING WASHER | 1.10 |
71 | 107JM | INTERNAL GEARS CONTACT SURFACE | 1.65 |
72 | 101R2 | COVER (A) | 67.65 |
73 | 10PV5 | SEAL (A) | 2.75 |
74 | 13AYY | HANDLE SHAFT FLANGE | 18.15 |
75 | 10JL7 | HANDLE SHAFT (LEFT HANDLE ONLY) | 9.35 |
76 | 13ASQ | HANDLE SHAFT FLANGE | 56.10 |
77 | 10A9T | HANDLE SHAFT BOLT | 3.85 |
78 | 104VX | BALL BEARING (4X7X2.5) | 13.75 |
79 | 13AYP | HANDLE KNOB | 9.35 |
80 | 104FH | WASHER | 2.20 |
81 | 103E9 | FIXING BOLT | 1.10 |
82 | 13AYX | HANDLE KNOB NAMEPLATE | 3.85 |
83 | 103NM | FIXING BOLT | 2.75 |
84 | 13AT5 | HANDLE ASSEMBLY | 112.20 |
85 | 10ML9 | FIXING BOLT | 1.10 |
86 | 103GQ | FIXING BOLT | 1.10 |
87 | 10HCH | SLIDER | 6.05 |
88 | 106QY | CROSS GEAR PIN | 3.85 |
89 | 10RKQ | WASHER | 2.20 |
90 | 10JVA | CROSS GEAR PIN COLLAR | 2.75 |
91 | 10H7L | CROSS GEAR PIN PUSH PLATE | 1.10 |
92 | 10LYX | FIXING BOLT | 1.10 |
93 | 10GQ9 | BODY GUARD (A) | 9.35 |
94 | 10TNR | FIXING BOLT | 2.75 |
95 | 10CT7 | BODY GUARD (B) | 9.35 |
96 | 107CJ | MAIN BODY COVER | 1.65 |
97 | 103EE | FIXING BOLT | 2.75 |
98 | 10BF2 | CROSS GEAR SHAFT COVER | 3.85 |
99 | 10H44 | CROSS GEAR SHAFT COVER SHEET | 1.65 |
100 | 103C8 | FIXING BOLT | 1.10 |
101 | 1032Z | SLIDER GUIDE (A) | 2.75 |
102 | 104M2 | SLIDER GUIDE (B) | 2.75 |
103 | 10PDA | BALL BEARING (3X6X2.5) | 13.75 |
104 | 10J1F | WASHER | 1.10 |
105 | 13ARK | BODY | 223.30 |
106 | 10CHH | DRIVE GEAR SIDE GUIDE | 17.05 |
107 | 10M83 | REDUCTION BUSH | 1.65 |
108 | 10CHK | WORM GEAR FOR WORM SHAFT GEAR | 9.35 |
109 | 10M81 | REDUCTION BUSHING (B) | 1.65 |
110 | 10MD4 | WORM GEAR SIDE GUIDE | 22.55 |
111 | 10M82 | REDUCTION BUSH | 1.65 |
112 | 13MMR | INTERMEDIATE GEAR | 9.35 |
113 | 10M7Z | WORM GEAR FOR PINION GEAR | 9.35 |
114 | 10706 | CROSS GEAR PIN ADJUSTMENT WASHER | 1.10 |
115 | 13AYL | COVER (B) | 22.55 |
116 | 108WS | O-RING 4X6 | 1.10 |
117 | 109LV | LUBRICATION HOLE CAP | 3.85 |
118 | 108WP | O-RING | 1.65 |
119 | 13AYA | HANDLE SCREW CAP | 13.75 |
120 | 10C2W | FIXING BOLT | 6.05 |
121 | 13CPM | LINE ROLLER (WITH BEARING) | 22.55 |
141 | 10FHS | HANDLE SHAFT (RIGHT H ONLY) (ACCESSORY) | 9.35 |
142 | 13K4B | SAND PROTECTOR (ACCESSORY) | 3.85 |
143 | 13R11 | SPOOL PROTECTOR | 6.05 |
144 | 10PBR | LEG PROTECTOR SHEET | 2.75 |
AC02 | 13QTP | NO. SEALS | 1.65 |
BNKI | 13B3V | EXPLODED VIEW (ACCESSORY) | 1.65 |
MH01 | 13AZF | NAMEPLATE ON THE BACK OF THE LEGS | 2.75 |
TRST | 13PMX | INSTRUCTION MANUAL (ACCESSORY) | 1.65 |
