[SHIMANO] Genuine Spare Parts for 17 Vanquish FW 1000SHG Product Code: 038135 **Back-order (Shipping in 3-4 weeks after receiving order)
Our Selling Price: US$0.77 [Regular Price: US$1.10]
Prices vary according to options.
Item Description
ATTENTION:
- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.
- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.
*Please make sure to read about the conditions before you order.
Reel Part's Schematic Diagram |
* Circled figures indicate bearings.
* Please note disassembly is at your own risk.
No. | S Part No. | Description | Price (USD) |
*F01 | 13QQ6 | REEL BAG (ACCESSORY) | 11.55 |
1 | 10QYL | DRAG KNOB SET | 28.05 |
2 | 10B8J | STOPPER SPRING | 1.65 |
3 | 10B9X | OVAL WASHER | 3.85 |
4 | 102ZF | DRAG WASHER | 1.65 |
5 | 104JT | BALL BEARING (6 X 10 X 3) | 13.75 |
6 | 10BQE | SPOOL PIN SPRING | 1.65 |
7 | 10388 | SPOOL PIN | 1.65 |
8 | 10A6F | FIXING BOLT | 1.65 |
10 | 10BU7 | SPOOL WASHER SET | 1.10 |
11 | 10PN2 | SET SCREW | 1.65 |
12 | 10LTR | SPOOL SHAFT BEARING GUIDE | 6.05 |
13 | 104PP | BALL BEARING (7 X 11 X 3) | 13.75 |
14 | 102VD | WASHER | 1.10 |
15 | 10TQG | DRAG CLICK SILATCHET | 2.75 |
16 | 103PC | SPOOL RECEIVER | 1.65 |
17 | 107V3 | RATCHET SPRING | 1.65 |
18 | 1055M | FIXING BOLT | 1.10 |
19 | 10TRG | RETAINER | 2.75 |
20 | 10R2D | ROTOR NUT | 3.85 |
21 | 10CH0 | BAIL TRIP LEVER CLICK SPRING | 1.65 |
22 | 10CHA | BAIL TRIP LEVER CLICK PIN | 1.65 |
23 | 10GAT | LINE ROLLER BEARING COLLAR | 6.05 |
24 | 10TSK | LINE ROLLER (WITH BEARING) | 22.55 |
25 | 1079U | ARM ROLLER BEARING COLLAR | 1.65 |
26 | 10K40 | FIXING BOLT | 2.75 |
27 | 103D9 | FIXING BOLT | 1.65 |
28 | 13KLC | ARM CAM | 6.05 |
29 | 13CPP | ROTOR ASSEMBLY | 56.10 |
30 | 10TRD | BAIL TRIP LEVER | 2.75 |
31 | 1064R | ARM SPRING GUIDE (A) COLLAR | 1.65 |
32 | 105R7 | ARM CAM SPRING | 1.65 |
33 | 10R2E | ARM CAM SPRING GUIDE (B) | 2.75 |
34 | 13CUZ | BAIL ASSEMBLY | 45.10 |
35 | 10R3U | WASHER | 1.65 |
36 | 10L01 | ARM FIXED SHAFT | 2.75 |
37 | 105YZ | ARM SPRING GUIDE (A) | 3.85 |
38 | 10R2F | ARM SPRING GUIDE (A) COLLAR BUSH | 1.65 |
39 | 10TPH | BALE MOUNTING COVER | 9.35 |
40 | 103KT | FIXING BOLT | 1.10 |
41 | 10MTG | FIXING BOLT | 1.65 |
42 | 10L61 | ROLLER CLUTCH COVER PLATE | 1.65 |
43 | 10SD7 | ROLLER CLUTCH SEAL ASSEMBLY | 11.55 |
44 | 10QYK | ROLLER CLUTCH ASSEMBLY | 12.65 |
45 | 10MLT | O-RING | 3.85 |
46 | 107S5 | ROLLER CLUTCH INNER COLLAR | 2.75 |
47 | 10H4G | ROLLER CLUTCH INNER COLLAR | 1.65 |
48 | 10ML6 | FIXING BOLT | 1.65 |
49 | 10593 | BEARING PUSH PLATE | 2.75 |
50 | 13L47 | BALL BEARING (7 X 13 X 4) | 13.75 |
51 | 10JDC | ADJUSTMENT WASHER SET | 1.10 |
53 | 10CJV | CROSS GEAR SHAFT COLLAR | 2.75 |
54 | 10J6E | PINION GEAR SPACER | 1.65 |
55 | 104K4 | BALL BEARING (5 X 8 X 2.5) | 13.75 |
56 | 10TNS | INTERMEDIATE GEAR SHAFT | 3.85 |
57 | 104FU | FRICTION RING | 3.85 |
58 | 10R1M | FIXING BOLT | 1.65 |
59 | 10R31 | INTERNAL GEARS | 1.65 |
60 | 10LPJ | FIXING BOLT | 1.65 |
61 | 10PC0 | BALL BEARING (2 X 5 X 2.5) | 13.75 |
62 | 10HBP | WORM SHAFT GEAR | 9.35 |
63 | 10J3N | FRICTION RING SPACER | 2.75 |
66 | 1055G | FIXING BOLT | 1.65 |
67 | 104JD | BALL BEARING (7 X 13 X 4) | 13.75 |
68 | 10CBC | FOOT FLANGE SEAL | 2.75 |
69 | 13DV9 | FOOT ASSEMBLY | 56.10 |
70 | 10M2C | FIXING BOLT | 1.10 |
71 | 10LUY | FIXING BOLT | 1.10 |
72 | 10C2G | FIXING BOLT WASHER FOR LID | 2.75 |
74 | 104VX | BALL BEARING (4 X 7 X 2.5) | 13.75 |
75 | 10327 | HANDLE KNOB | 11.55 |
76 | 104FH | WASHER | 2.20 |
77 | 103E9 | FIXING BOLT | 1.10 |
78 | 10TNJ | HANDLE CAP | 3.85 |
80 | 10HAG | WORM SHAFT PIN PUSH PLATE | 1.65 |
81 | 10JXQ | WORM SHAFT PIN COLLAR | 2.75 |
82 | 10RKQ | WORM SHAFT PIN COLLAR | 2.20 |
83 | 106VK | WORM SHAFT PIN | 4.95 |
84 | 101QW | MAIN SHAFT ASSEMBLY | 28.05 |
85 | 10NL3 | BODY GUARD | 11.55 |
86 | 106ZG | FIXING BOLT | 1.65 |
87 | 107HH | BODY COVER | 1.65 |
88 | 10AYN | BODY GUARD COLLAR | 2.75 |
89 | 103LH | FIXING BOLT | 2.75 |
90 | 10AT9 | WORM SHAFT COVER | 1.65 |
91 | 10PDA | BALL BEARING (3 X 6 X 2.5) | 13.75 |
92 | 10J7K | WASHER | 1.10 |
93 | 1068D | WORM SHAFT | 11.55 |
94 | 10JAB | O-RING | 1.65 |
95 | 1035K | SLIDER GUIDE (A) | 3.85 |
96 | 104MA | SLIDER GUIDE (B) | 3.85 |
97 | 106RJ | INTERMEDIATE GEAR (S) | 8.25 |
98 | 1059T | WASHER | 1.10 |
101 | 108WA | O-RING | 1.65 |
121 | 10PBS | LEG PROTECTION SHEET (ACCESSORY) | 2.75 |
131 | 13CFF | SPOOL ASSEMBLY | 101.20 |
132 | 10TQ8 | PINION GEAR | 20.35 |
133 | 101RD | DRIVE GEAR ASSEMBLY | 28.05 |
134 | 13E1U | HANDLE SHAFT ASSEMBLY | 67.65 |
135 | 13EQV | HANDLE ASSEMBLY | 112.20 |
136 | 10CQE | INTERMEDIATE GEAR (L) | 9.35 |
137 | 13DCV | BODY ASSEMBLY | 157.30 |
138 | 13LU7 | HANDLE SCREW CAP | 11.55 |
BNKI | 13R4F | EXPLODED VIEW (ACCESSORIES) | 1.65 |
ITOS | 13QPZ | THREAD STOPPER SEAL | 1.65 |
TRST | 13PMG | INSTRUCTION MANUAL (ACCESSORY) | 1.65 |
