[SHIMANO] Genuine Spare Parts for 17 Vanquish FW 1000S Product Code: 038128 **Back-order (Shipping in 3-4 weeks after receiving order)

[SHIMANO] Genuine Spare Parts for 17 Vanquish FW 1000S Product Code: 038128 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.66 [Regular Price: US$1.10]

Prices vary according to options.

View availability
Part Number:
Quantity:
Contact Us

Item Description

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.

　Reel Part's Schematic Diagram


* Circled figures indicate bearings.
* Please note disassembly is at your own risk.

No. S Part No. Description Price (USD)
*F01 13QQ6 REEL BAG (ACCESSORY) 11.55
1 10QYL DRAG KNOB SET 28.05
2 10B8J STOPPER SPRING 1.65
3 10B9X OVAL WASHER 3.85
4 102ZF DRAG WASHER 1.65
5 104JT BALL BEARING (6 X 10 X 3) 13.75
6 10BQE SPOOL PIN SPRING 1.65
7 10388 SPOOL PIN 1.65
8 10A6F FIXING BOLT 1.65
9 13CFE SPOOL ASSEMBLY 101.20
10 10BU7 SPOOL WASHER SET 1.10
11 10PN2 SET SCREW 1.65
12 10LTR SPOOL SHAFT BEARING GUIDE 6.05
13 104PP BALL BEARING (7 X 11 X 3) 13.75
14 102VD WASHER 1.10
15 10TQG DRAG CLICK SILATCHET 2.75
16 103PC SPOOL RECEIVER 1.65
17 107V3 RATCHET SPRING 1.65
18 1055M FIXING BOLT 1.10
19 10TRG RETAINER 2.75
20 10R2D ROTOR NUT 3.85
21 10CH0 BAIL TRIP LEVER CLICK SPRING 1.65
22 10CHA BAIL TRIP LEVER CLICK PIN 1.65
23 10GAT LINE ROLLER BEARING COLLAR 6.05
24 10TSK LINE ROLLER (WITH BEARING) 22.55
25 1079U ARM ROLLER BEARING COLLAR 1.65
26 10K40 FIXING BOLT 2.75
27 103D9 FIXING BOLT 1.65
28 13KLC ARM CAM 6.05
29 13CPP ROTOR ASSEMBLY 56.10
30 10TRD BAIL TRIP LEVER 2.75
31 1064R ARM SPRING GUIDE (A) COLLAR 1.65
32 105R7 ARM CAM SPRING 1.65
33 10R2E ARM CAM SPRING GUIDE (B) 2.75
34 13CUZ BAIL ASSEMBLY 45.10
35 10R3U WASHER 1.65
36 10L01 ARM FIXED SHAFT 2.75
37 105YZ ARM SPRING GUIDE (A) 3.85
38 10R2F ARM SPRING GUIDE (A) COLLAR BUSH 1.65
39 10TPH BALE MOUNTING COVER 9.35
40 103KT FIXING BOLT 1.10
41 10MTG FIXING BOLT 1.65
42 10L61 ROLLER CLUTCH COVER PLATE 1.65
43 10SD7 ROLLER CLUTCH SEAL ASSEMBLY 11.55
44 10QYK ROLLER CLUTCH ASSEMBLY 12.65
45 10MLT O-RING 3.85
46 107S5 ROLLER CLUTCH INNER COLLAR 2.75
47 10H4G ROLLER CLUTCH INNER COLLAR 1.65
48 10ML6 FIXING BOLT 1.65
49 10593 BEARING PUSH PLATE 2.75
50 13L47 BALL BEARING (7 X 13 X 4) 13.75
51 10JDC ADJUSTMENT WASHER SET 1.10
52 10TQ7 PINION GEAR 20.35
53 10CJV CROSS GEAR SHAFT COLLAR 2.75
54 10J6E PINION GEAR SPACER 1.65
55 104K4 BALL BEARING (5 X 8 X 2.5) 13.75
56 10TNS INTERMEDIATE GEAR SHAFT 3.85
57 104FU FRICTION RING 3.85
58 10R1M FIXING BOLT 1.65
59 10R31 INTERNAL GEARS 1.65
60 10LPJ FIXING BOLT 1.65
61 10PC0 BALL BEARING (2 X 5 X 2.5) 13.75
62 10HBP WORM SHAFT GEAR 9.35
63 10J3N FRICTION RING SPACER 2.75
64 101RC DRIVE GEAR ASSEMBLY 28.05
66 1055G FIXING BOLT 1.65
67 104JD BALL BEARING (7 X 13 X 4) 13.75
68 10CBC FOOT FLANGE SEAL 2.75
69 13DV9 FOOT ASSEMBLY 56.10
70 10M2C FIXING BOLT 1.10
71 10LUY FIXING BOLT 1.10
72 10C2G COVER FIXING BOLT WASHER 2.75
73 13E1T HANDLE SHAFT ASSEMBLY 67.65
74 104VX BALL BEARING (4 X 7 X 2.5) 13.75
75 10327 HANDLE KNOB 11.55
76 104FH WASHER 2.20
77 103E9 FIXING BOLT 1.10
78 10TNJ HANDLE CAP 3.85
79 13EQU HANDLE ASSEMBLY 112.20
80 10HAG WORM SHAFT PIN PUSH PLATE 1.65
81 10JXQ WORM SHAFT PIN COLLAR 2.75
82 10RKQ WASHER 2.20
83 106VK WORM SHAFT PIN 4.95
84 101QW MAIN SHAFT ASSEMBLY 28.05
85 10NL3 BODY GUARD 11.55
86 106ZG FIXING BOLT 1.65
87 107HH BODY COVER 1.65
88 10AYN BODY GUARD COLLAR 2.75
89 103LH FIXING BOLT 2.75
90 10AT9 WORM SHAFT COVER 1.65
91 10PDA BALL BEARING (3 X 6 X 2.5) 13.75
92 10J7K WASHER 1.10
93 1068D WORM SHAFT 11.55
94 10JAB O-RING 1.65
95 1035K SLIDER GUIDE (A) 3.85
96 104MA SLIDER GUIDE (B) 3.85
97 106RJ INTERMEDIATE GEAR (S) 8.25
98 1059T WASHER 1.10
99 10CQD INTERMEDIATE GEAR (L) 9.35
100 13DC1 BODY ASSEMBLY 157.30
101 108WA O-RING 1.65
102 13LU6 HANDLE SCREW CAP 11.55
121 10PBS LEG PROTECTION SHEET (ACCESSORY) 2.75
BNKI 13R4F EXPLODED VIEW (ACCESSORY) 1.65
ITOS 13QPZ THREAD STOPPER STICKER 1.65
TRST 13PMG INSTRUCTION MANUAL (ACCESSORY) 1.65
