[SHIMANO] Genuine Spare Parts for 15 TWIN POWER C2000S Product Code: 033642 **Back-order (Shipping in 3-4 weeks after receiving order)
Our Selling Price: US$0.77 [Regular Price: US$1.10]
Prices vary according to options.
Item Description
ATTENTION:
- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.
- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.
*Please make sure to read about the conditions before you order.
Reel Part's Schematic Diagram |
* Circled figures indicate bearings.
* Please note disassembly is at your own risk.
No. | S Part No. | Description | Price (USD) |
1 | 10GZY | DRAG KNOB ASSEMBLY | 17.05 |
2 | 10B8J | STOPPER SPRING | 1.65 |
3 | 10B9X | OVAL WASHER | 3.85 |
4 | 102ZF | DRAG WASHER | 1.65 |
5 | 104JT | BALL BEARING (6 X 10 X 3) | 13.75 |
6 | 10388 | SPOOL PIN | 1.65 |
7 | 10BQE | SPOOL PIN SPRING | 1.65 |
8 | 10A6F | FIXING BOLT | 1.65 |
10 | 10BU7 | SPOOL WASHER SET | 1.10 |
11 | 10PN2 | SET SCREW | 1.65 |
12 | 10LTR | SPOOL SHAFT BEARING GUIDE | 6.05 |
13 | 104PP | BALL BEARING (7 X 11 X 3) | 13.75 |
14 | 102VD | WASHER | 1.10 |
15 | 107V0 | DRAG CLICK RATCHET | 2.75 |
16 | 103PC | SPOOL RECEIVER | 1.65 |
17 | 107V3 | RATCHET SPRING | 1.65 |
18 | 10PMD | FIXING BOLT | 1.10 |
19 | 1076P | RETAINER | 2.75 |
20 | 107L3 | ROTOR BEARING SEAL | 2.75 |
21 | 1067W | ROTOR NUT | 9.35 |
22 | 10GAR | LINE ROLLER BEARING COLLAR | 2.75 |
23 | 10N6E | LINE ROLLER (WITH BEARING) | 22.55 |
24 | 10HWT | LINE ROLLER RECEIVER | 1.65 |
25 | 10CH0 | BAIL TRIP LEVER CLICK SPRING | 1.65 |
26 | 10CHA | BAIL TRIP LEVER CLICK PIN | 1.65 |
27 | 106KZ | BAIL TRIP LEVER CLICK SPRING | 2.75 |
28 | 105YZ | ARM SPRING GUIDE (A) | 3.85 |
29 | 1064R | ARM SPRING GUIDE (A) COLLAR | 1.65 |
30 | 105R7 | ARM CAM SPRING | 1.65 |
31 | 107AC | ARM CAM SPRING SEAT | 2.75 |
32 | 10KLV | ARM CAM | 6.05 |
33 | 10PS3 | FIXING BOLT | 1.10 |
34 | 10PS4 | FIXING BOLT | 1.10 |
35 | 10PS6 | FIXING BOLT | 1.10 |
36 | 108BZ | ARM CAM SPRING COVER | 6.05 |
37 | 10Q1V | ROTOR | 22.55 |
38 | 1055B | FIXING BOLT | 1.10 |
39 | 10MNN | BALE MOUNTING BRACKET COVER | 11.55 |
40 | 103N4 | FIXING BOLT | 1.10 |
41 | 10L01 | ARM FIXING SHAFT | 2.75 |
42 | 103AK | BALE ASSEMBLY | 34.10 |
44 | 10MTE | FIXING BOLT | 1.10 |
45 | 10L61 | ROLLER CLUTCH COVER PLATE | 1.65 |
48 | 10MLT | O-RING | 3.85 |
49 | 107S5 | ROLLER CLUTCH INNER COLLAR | 2.75 |
50 | 10H4G | ROLLER CLUTCH INNER COLLAR | 1.65 |
51 | 10ML6 | FIXING BOLT | 1.65 |
52 | 10593 | BEARING PUSH PLATE | 2.75 |
55 | 10CJV | CROSS GEAR SHAFT COLLAR | 2.75 |
56 | 10J6E | PINION GEAR SPACER | 1.65 |
58 | 10CL9 | INTERMEDIATE GEAR SHAFT | 3.85 |
59 | 107DZ | INNER GEAR CONTACT | 1.65 |
60 | 104FU | FRICTION RING | 3.85 |
61 | 10AYS | BODY FLANGE SEAL | 2.75 |
62 | 10LPQ | FIXING BOLT | 1.10 |
63 | 106M8 | WORM SHAFT BUSH (FRONT) | 2.75 |
64 | 10HET | WORM SHAFT GEAR | 6.05 |
65 | 10J3N | FRICTION RING SPACER | 2.75 |
67 | 10JDC | ADJUSTMENT WASHER SET | 1.10 |
68 | 1055G | FIXING BOLT | 1.65 |
69 | 104JD | BALL BEARING (7 X 13 X 4) | 13.75 |
70 | 10CBC | FOOT FLANGE SEAL | 2.75 |
71 | 104HS | FOOT | 39.60 |
72 | 10M2C | FIXING BOLT | 1.10 |
73 | 10LUY | FIXING BOLT | 1.10 |
74 | 10C2G | COVER FIXING BOLT WASHER | 2.75 |
75 | 10PXU | HANDLE SHAFT SEAL | 2.75 |
76 | 10PQH | HANDLE SHAFT FLANGE (B) | 8.25 |
77 | 10C4H | HANDLE SHAFT FLANGE | 14.85 |
79 | 104VX | BALL BEARING (4 X 7 X 2.5) | 13.75 |
80 | 10327 | HANDLE KNOB | 11.55 |
81 | 10G8G | WASHER | 1.10 |
82 | 103E9 | FIXING BOLT | 1.10 |
85 | 10HAG | WORM SHAFT PIN PUSH PLATE | 1.65 |
86 | 10JXU | WORM SHAFT PIN COLLAR | 2.75 |
87 | 10RKQ | WASHER | 2.20 |
88 | 106VK | WORM SHAFT PIN | 4.95 |
89 | 102J4 | MAIN SHAFT ASSEMBLY | 28.05 |
90 | 10NL3 | BODY GUARD | 11.55 |
91 | 10PRY | FIXING BOLT | 1.10 |
92 | 107HH | BODY COVER | 1.65 |
93 | 10AYN | BODY GUARD COLLAR | 2.75 |
94 | 103LG | FIXING BOLT | 1.10 |
95 | 10ATA | WORM SHAFT COVER | 1.65 |
96 | 106CM | CROSS GEAR BUSH (FRONT) | 1.65 |
97 | 10J7K | WASHER | 1.10 |
98 | 1068D | WORM SHAFT | 11.55 |
99 | 10JAB | O-RING | 1.65 |
100 | 1035R | SLIDER GUIDE (A) | 2.75 |
101 | 104ME | SLIDER GUIDE (B) | 2.75 |
102 | 106VS | INTERMEDIATE GEAR (S) | 8.25 |
103 | 1059T | WASHER | 1.10 |
106 | 10N16 | HANDLE SCREW CAP | 11.55 |
107 | 10HVD | WASHER | 1.10 |
108 | 10HV8 | WASHER | 1.10 |
110 | 104JC | BALL BEARING (7 X 13 X 4) | 13.75 |
111 | 104JY | BALL BEARING (5 X 8 X 2.5) | 13.75 |
112 | 10DG6 | ROLLER CLUTCH ASSEMBLY | 12.65 |
113 | 13EQL | ROLLER CLUTCH SEAL ASSEMBLY | 11.55 |
114 | 10FMJ | HANDLE CAP | 2.75 |
121 | 1089M | SPOOL ASSEMBLY | 92.40 |
122 | 10C4R | PINION GEAR | 12.65 |
123 | 10ELW | DRIVE GEAR ASSEMBLY | 28.05 |
124 | 103WE | HANDLE | 39.60 |
125 | 10NEJ | HANDLE ASSEMBLY | 78.65 |
126 | 10CQP | INTERMEDIATE GEAR (L) | 9.35 |
127 | 102GG | BODY | 67.65 |
*F01 | 13QN1 | REEL BAG | 3.85 |
BNKI | 13R0J | EXPLODED VIEW (ACCESSORIES) | 1.65 |
ITOS | 13QPZ | STOPPER SEAL | 1.65 |
MH01 | 13NEP | NAMEPLATE ON THE BACK OF THE FOOT | 2.75 |
TRST | 13PMG | INSTRUCTION MANUAL (ACCESSORY) | 1.65 |
