  3. > [SHIMANO] 12 ANTARES Genuine Parts List - Schematic Diagram & Parts Diagram
  4. > [SHIMANO] Genuine Spare Parts for 12 ANTARES HG R Product code: 028372 **Back-order (Shipping in 3-4 weeks after receiving order)

[SHIMANO] Genuine Spare Parts for 12 ANTARES HG R Product code: 028372 **Back-order (Shipping in 3-4 weeks after receiving order)

[SHIMANO] Genuine Spare Parts for 12 ANTARES HG R Product code: 028372 **Back-order (Shipping in 3-4 weeks after receiving order)

Our Selling Price: US$0.77 [Regular Price: US$1.10]

Prices vary according to options.

View availability
Part Number:
Quantity:
Contact Us

Item Description

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.



*Please make sure to read about the conditions before you order.

　Reel Part's Schematic Diagram


* Circled figures indicate bearings.
* As for the "118 / ROLLER CLUTCH", they don't sell separately.
These parts are supposed to be provided when customers send the reel to have it repaired or overhauled.
So we cannot provide you with the products unfortunately.
* Please note disassembly is at your own risk.

No. S Part No. Description Price (USD)
*F01 13WHX REEL BAG (ACCESSORY) 9.35
1 10Q5W HANDLE RETAINER 6.05
2 103N8 FIXING BOLT 1.10
3 10FFH HANDLE FIXING NUT 6.05
4 10AVV HANDLE CAP 1.65
5 103E9 FIXING BOLT 1.10
6 104VX BALL BEARING (4 X 7 X 2.5) 13.75
7 104FH WASHER 2.20
8 10329 HANDLE KNOB 11.55
9 109VL KNOB FIXING SHAFT PIPE 3.85
12 10KXV STAR DRAG CLICK PLATE RETAINER 1.65
14 10BT0 CLICK PIN 1.65
17 10A71 STAR DRAG SPRING 2.75
18 10A0B STAR DRAG FIXING NUT 2.75
19 10J1N STAR DRAG SPACER 1.65
20 10D60 MAIN GEAR WASHER (C) 1.65
21 105PW STAR DRAG BEARING WASHER 1.10
22 10EX8 BALL BEARING (8 X 12 X 3.5) 13.75
23 10K0A BODY A NAMEPLATE 2.75
24 103N4 FIXING BOLT 1.10
25 10KFU MECHANICAL BRAKE KNOB 22.55
26 10CCX SD KNOB NAMEPLATE 1.65
27 10C5Z NAMEPLATE SHEET 2.75
28 10896 MECHANICAL BRAKE WASHER 1.10
29 1057S SPOOL SHAFT CONTACT (B) 1.10
30 10L2F MECHANICAL BRAKE KNOB CLICK PLATE 2.75
31 10L6Y MECHANICAL BRAKE KNOB CLICK HOLDER 2.75
32 10GEW BEARING RETAINING CLAMP 1.10
33 105C0 BALL BEARING (3 X 10 X 4) 13.75
34 10EYU BEARING SPACER 2.75
35 105BP BALL BEARING (5 X 9 X 3) 13.75
36 108W8 O-RING S-16 1.65
40 10BN1 ROLLER CLUTCH INNER TUBE 6.05
44 10CHZ STAR DRAG WASHER 2.75
45 10D77 STOPPER GEAR 3.85
46 105CX DRIVE GEAR SHAFT 22.55
47 10J77 CROSS GEAR (A) 3.85
48 10MT2 FIXING BOLT 1.10
49 109T5 MAIN GEAR SHAFT FIXING PLATE 1.65
50 104JZ BALL BEARING (5 X 8 X 2.5) 13.75
51 10C47 MAIN GEAR SHAFT WASHER 1.10
52 105NK TYPE E RETAINING RING 2.5 1.10
53 10FP4 CROSS GEAR (C) 2.75
54 10G84 CROSS GEAR (C) 1.10
55 10NCZ WORM SHAFT RECEIVER (A) 1.65
56 104ZN WORM SHAFT 17.05
57 10NJH LEVEL-WIND PIPE 6.05
58 10QSL LEVEL-WIND ROD 2.75
60 104BU CLUTCH YOKE SPRING 1.10
61 1046S CLUTCH YOKE 1.65
62 10LVH CLUTCH CAM FIXING BOLT 1.10
63 10F43 CLUTCH CAM PUSH PLATE 9.35
64 10KSB CLUTCH CAM 2.75
65 105ZU CLUTCH CLAW 3.85
66 1048C CLUTCH CLAW BUSHING 1.65
67 10N1Z CLUTCH CLAW SPRING 1.10
68 10QLP CLUTCH PLATE 4.95
69 103C0 FIXING BOLT 1.10
70 10BVX BODY A SEAT 3.85
71 103CG FIXING BOLT 1.10
72 105NB E TYPE STOP RING 1.5 1.10
73 1099B CLUTCH LEVER RECEIVER (B) 1.65
74 10MXW CLUTCH LEVER 9.35
75 10MT8 FIXING BOLT 1.10
76 10QH1 LEVEL WIND GUARD 9.35
77 10MPR BODY A SEAT B FIXING BOLT 1.10
78 10FJD LEVEL WINDING RECEIVER 3.85
79 10CFW ADJUSTMENT WASHER SET 1.10
80 10FFW WORM SHAFT PIN 2.75
81 108WQ O RING 1.65
82 10NYQ LEVEL WINDING ASSEMBLY 22.55
83 104N7 THUMB REST 50.60
84 10LVD FIXING BOLT 1.10
85 10LVL FIXING BOLT 1.10
86 104SR WORM SHAFT RECEIVER (B) 1.65
88 105NC E TYPE RETAINING RING 2 1.10
89 10LUY FIXING BOLT 1.10
90 108SK WASHER 1.10
91 108Q2 BODY FRAME ATTACHMENT WASHER 1.10
93 10L7Q SPOOL ASSEMBLY 101.20
94 1046M BRAKE SHOE (M) RED 1.10
95 13RRU BRAKE SHOE (L) BLACK 1.10
96 10EXU BRAKE PIPE GEAR 9.35
98 10LVA FIXING BOLT 1.10
100 104N6 BODY B CAM LEVER ADJUSTMENT WASHER 1.65
101 10BBW BODY B CAM LEVER 1.65
102 108F1 BODY B RECEIVING KE ADJUSTMENT WASHER 1.10
103 10A6M FIXING BOLT 3.85
104 10B21 BR KNOB 14.85
105 10BGN BR KNOB GEAR 1.65
106 10CLG INTERMEDIATE GEAR 1.65
107 10B4Z CLICK PIN 1.65
108 10B51 CLICK SPRING 1.10
109 10HU4 BODY B ASSEMBLY 62.15
110 10CFV WAGON WAGON 1.10
111 10HHN SLIDER WASHER (9 X 13 X 0.3) 1.65
112 10KNE DAMPER SPRING 1.65
114 10HWE MECHANICAL BRAKE KNOB ASSEMBLY 34.65
115 10FXX FRAME B RECEIVER ASSEMBLY 11.55
116 10988 CLICK SPRING 1.65
117 105EK CLICK BUTTON WASHER 1.10
118 10F33 ROLLER CLUTCH *Cannot be ordered 22.55
119 10J26 STAR DRAG CLICK PLATE 1.65
121 10MDK REEL WRENCH (ACCESSORY) 3.85
122 1046N BRAKE SHOE (S) (ACCESSORY) WHITE 1.10
132 109VF HANDLE 34.10
133 10CFG HANDLE ASSEMBLY 90.20
134 10J37 MAIN BODY A SET 123.75
135 10D3N STAR DRAG PLATE 2.75
136 1071T STAR DRAG WASHER 4.95
137 10CRA DRIVE GEAR 28.05
138 10CU7 PINION GEAR 22.55
139 10JNR FRAME 123.75
140 10AX9 STAR DRAG 28.05
BNKI 13WL3 EXPLODED VIEW (ACCESSORIES) 1.65
OIL1 10LQ0 B-100 OIL (4.5G) 3.85
TRST 13VJJ INSTRUCTION MANUAL (ACCESSORY) 1.65
