[SHIMANO] "Kattobi" Spool Bearing Kit - AIR BFS SW- [1030AIR BFS SW & 1030AIR BFS SW] [AIR BFS SW Bearing] for ANTARES, CALCUTTA CONQUEST, ALDEBARAN, Metanium, Scorpion, SLX, EXSENCE

Product Description

*With an instruction manual included, even beginners can easily replace the bearings.
*This product is a set of two tuning bearings designed specifically for bait reel spools.
*If you do not have a pin removal tool, we recommend purchasing one together.
→ For more information about the Spool Bearing Remover, please see here.


AIR BFS is a new anti-rust bearing for saltwater applications that offers overwhelming rotational performance.
The AIR BFS (Bait Finesse Special) bearing has a detachable housing, allowing for the replacement of worn internal bearings.
The extremely small micro balls characteristic of AIR Bearings are made from high-precision stainless steel, providing excellent noise reduction during rotation.

The AIR BFS SW Bearing helps cast bait finesse and lightweight plugs in any field, whether freshwater or saltwater.

*AIR BFS SW bearings are double-sided shielded bearings.


AIR Bearing Technology







The AIR BFS SW bearing allows easy replacement of the main micro bearing from the outer housing by removing the built-in stopper ring.
This bearing has a high cost-performance ratio due to its easy-to-maintain construction.
Anti-rust micro bearings and stopper rings for replacement are also available separately.



Anti-rust micro bearings for replacement HRCB-630ZHi



Dedicated stopper ring 6 mm




* When fully casting a lure weighing 20g or more, the maximum reachable distance is about the same for all bearings, but the AIR bearing series is easier to control at short distances such as pitching.
(For lightweight lures weighing less than 20g, the AIR bearing series will increase the distance of a full cast compared to a regular bearing.)

* AIR BFS bearings are a cost-reduced version of AIR ceramic bearings.
It does not mean that AIR BFS bearings are more likely to produce greater distance when used in bait finesse than AIR ceramic bearings.
Even if only ultra-lightweight lures are used, the AIR ceramic bearing will provide superior total balance.

* If you want to use the highest performance bearing, choose the AIR Ceramic Series.
Lure weighing less than 20g → AIR Ceramic Bearing
Lure weighing more than 20g or used mostly in saltwater → AIR HD Ceramic Bearing

* The above recommended weights are for casting. Even heavier loads can be applied when not making full casts, such as jigging or offshore fishing.
(AIR Ceramic Bearing is recommended for offshore fishing when increasing the sinking speed of the trap is important, and AIR HD Ceramic Bearing is recommended for jigging main use.)

* All bearings can be used in saltwater, but the AIR HD ceramic bearing has the best corrosion resistance, followed by the ZHi bearing.


Compatible Models

[Baitcasting Reel Series]

* AIR BFS Bearing is NOT useful for 16 Stile PG, XG and 15 ALDEBARAN 50/51.
For those reels, we definitely recommend AIR Ceramic Bearing (1030AIR & 1030AIR).

- 23 ANTARES DC MD HG RIGHT, HG LEFT, XG RIGHT, XG LEFT
- 21 ANTARES NORMAL, HG, XG
- 12 ANTARES NORMAL, HG
- 06 ANTARES AR, DC, DC7
- 98 Scorpion ANTARES Early Model, Ver.2, 5

- 18 ALDEBARAN MGL 30, 31, 30HG, 31HG
- 09 ALDEBARAN Mg, Mg7

- 24 Metanium DC 70, 71, 70HG, 71HG, 70XG, 71XG
- 15 Metanium DC NORMAL, HG, XG
- 13 Metanium NORMAL, HG, XG
- 08 Metanium MgDC, MgDC7
- 07 Metanium Mg, Mg7
- 05 Metanium XT
- 00 Metanium Mg

- 24 Scorpion MD 200HG, 201HG, 200XG, 201XG
- 21 Scorpion DC 150, 151, 150HG, 151HG, 150XG, 151XG
- 19 Scorpion MGL 150, 151, 150HG, 151HG, 150XG, 151XG
- 17 Scorpion DC 100, 101, 100HG, 101HG
- 16 Scorpion 70 NORMAL, HG, XG
- 14 Scorpion 200, 201, 200HG, 201HG
- 11 Scorpion DC, DC7
- 10 Scorpion XT 1000, 1001
- 09 Scorpion XT 1500, 1501, 7
- 04 Scorpion Mg 1000, 1001
- 03 Scorpion Quickfire
- 00 Scorpion 1000, 1001
- 97 Scorpion 1500, 1501
- 97 Scorpion Metanium XT (Silver meta)
- 94 Scorpion Quickfire
- 93 Scorpion 1500, 1501 *C
- 92 Bantam Scorpion Metanium XT (Red meta)*C

- 24 SLX 70 RIGHT, 71 LEFT, 70HG RIGHT, 71HG LEFT, 70XG RIGHT, 71XG LEFT
- 22 SLX DC XT 70, 71, 70HG, 71HG, 70XG, 71XG
- 20 SLX DC 70, 71, 70HG, 71HG, 70XG, 71XG
- 19 SLX MGL 70, 71, 70HG, 71HG, 70XG, 71XG

- 22 CURADO DC 200HG, 201HG, 200XG, 201XG
- 15 CURADO 200, 201 PG, NORMAL, HG


- 17 CHRONARCH MGL 150, 151, 150HG, 151HG, 150XG, 151XG
- 14 CHRONARCH CI4+ 150, 151, 150HG, 151HG

- 16 GRAPPLER BB 200HG, 201HG

- 22 EXSENCE DC R, L
- 20 EXSENCE DC SS HG, XG
- 12-13 EXSENCE DC

- 16 CASITAS MGL

- 09 CARDIFF 50SDC, 51SDC

- 10 Amenista

- 02 AXIS Ver.2, 100, 101, 400F, 401F
- 00 AXIS 100, 101

- 05 BASS RISE

- 11 BASS ONE XT
- 05 BASS ONE XT 200

- 14 Brenious

- 08 CHROMICA 100B


[CALCUTTA series]

- 20 CALCUTTA CONQUEST 100DC, 101DC, 100HGDC, 101HGDC, 200HGDC, 201HGDC
- 19 CALCUTTA CONQUEST 200DC, 201DC
- 15 CALCUTTA CONQUEST 100HG, 101HG, 200HG, 201HG
- 14 CALCUTTA CONQUEST 100, 101, 200, 201
- 15 OCEA CONQUEST 200PG, 201PG
- 14 OCEA CONQUEST 200HG, 201HG

- 13 OCEA CALCUTTA 300HG, 301HG *C
- 12 OCEA CALCUTTA 200PG, 201PG *C
- 11 OCEA CALCUTTA 200HG, 201HG *C
- 10 OCEA CALCUTTA CONQUEST 200 TypeJ-HG, 201 TypeJ-HG, 200 TypeJ-PG, 300 TypeJ-HG

- 07 CALCUTTA CONQUEST 300 Type J-M
- 06 CALCUTTA CONQUEST 300 Type J

- 12 CALCUTTA 100, 101, 200, 201 *C
- 13 CALCUTTA 300, 301, 400, 401
- 12 CALCUTTA 300F, 301F, 400F, 401F *C

- 11 CALCUTTA CONQUEST 50DC, 51DC *C
- 03, 04, 09, 10 CALCUTTA CONQUEST 100DC, 101DC, 200DC, 201DC
- 00, 01 CALCUTTA CONQUEST 100, 101, 200, 201, 300
- 05 CALCUTTA 100, 101, 200, 201, 400
- CALCUTTA XT 100, 101, 200, 201 *C
- Early CALCUTTA 100, 200 *C

- 07 CALCUTTA CONQUEST SUMIIKA Special
- 06 CALCUTTA ISO- 400, 700
- 04,05CALCUTTA CONQUEST 300F, 301F, 400F, 401F, 800F, 1000F, 1001F


[Ship Series]

- 08-09 CURADO 300 Type J/H 300J, 301J, 300J-H, 301J-H
- 08-09 CURADO 200 Type J 200J, 201J

- 16-17 ENGETSU 100PG, 101PG, 100HG, 101HG
- 16-17 ENGETSU BB 100PG, 101PG, 100HG, 101HG
- 09 ENGETSU NORMAL, 7
- 10 ENGETSU BB NORMAL, HG, PG

- 14 BAY GAME 300, 301, 300HG, 301HG
- 10 BAY GAME Type G 300, 301
- 10 BAY GAME HG Type G 300HG, 301HG
- 07 BAY GAME 300F, 301F

- 14 Barchetta CI4+ 200HG, 300HG
- 14 Barchetta BB 200HG, 300HG

- 12 GENPU Type G 300, 301
- 11 GENPU XT Type G 300XT, 301XT

- 11 Salty One HG, PG

- 06 SPEEDMASTER 200, 201

- 06 SPEEDMASTER 200, 201
- 09 BIOCRAFT Quickfire 300XH, 300XH Type G
- 08 BIOCRAFT 300XH
- 02 BIOCRAFT 400F


How to replace bearings in SHIMANO Baitcasting Reels



This bearing kit is to replace two bearings of a reel spool.
Normally, one is on the "SVS Brake side", and the other one is "under the mechanical knob cap" on the handle side.

For further details, please visit the following link.




About Spool Shaft Bearings *C

Reels marked with *C have a bearing on the spool shaft and the two bearings on the side cover plate side and the mechanical brake knob side.

The size of the spool shaft bearing is 1150ZZ size (inner diameter 5mm x outer diameter 11mm x thickness 4mm ).
If necessary, please purchase your favorite type of bearing separately.
⇒1150AIR HD or 1150AIR or 1150AIR BFS or 1150ZR or 1150ZHi


How to replace bearings in other DC-equipped reels

The following reels have bearings in the DC unit, so the replacement method on the side cover plate side is different from the usual method.

Please refer to the detailed replacement procedure for each reel.
