[SHIMANO Genuine] 20 EXSENCE DC SS Spare Spool (HG R, HG L, XG R, XG L) Product code: 041876/No.90/S Part No. 13GGQ/SPOOL ASSEMBLY **Back-order (Shipping in 3-4 weeks after receiving order)

ATTENTION:

- US$5.00 commission will be charged additionally.
* Select "+US$5.00 for Genuine Parts" for commission in STEP 2 on the order screen.

- It takes about 3 to 4 weeks for us to get ready to ship the items after you order.

- We don't accept order cancellations, changes, or refunds after an order unless the products you ordered are not available because SHIMANO/DAIWA Japan doesn't accept our cancellations.



*Please make sure to read about the conditions before you order.

Reel Part's Schematic Diagram

* Circled figures indicate bearings.
* As for the "205 / ROLLER CLUTCH", they don't sell separately.
These parts are supposed to be provided when customers send the reel to have it repaired or overhauled.
So we cannot provide you with the products unfortunately.
* Please note disassembly is at your own risk.

No.	S Part No.	Description	Price (USD)
1	10R1Q	FIXING BOLT	1.65
2	10SSK	RETAINER	3.85
3	101M3	HANDLE FIXING NUT	2.75
4	13XY5	HANDLE CAP	4.95
5	10LAA	O-RING	1.10
6	10LFA	FIXING BOLT	1.10
7	1003Z	WASHER	2.75
8	10PXZ	HANDLE KNOB BUSH	1.65
9	13MHS	WASHER	2.75
13	10KXW	STAR DRAG CLICK PLATE EXTRACTION STOP	1.65
14	10J26	STAR DRAG CLICK PLATE	1.65
15	10BT0	CLICK PIN	1.65
16	10BT2	CLICK SPRING	1.65
17	13V3W	STAR DRAG	11.55
18	10A70	STAR DRAG SPRING	2.75
19	10A3T	STAR DRAG FIXING NUT	3.85
20	10J1N	STAR DRAG SPACER	1.65
21	109F5	DRIVE GEAR WASHER	1.65
22	105PW	STAR DRAG BEARING WASHER	1.10
23	10EX8	BALL BEARING (8 X 12 X 3.5)	13.75
24	13U1T	MECHANICAL BRAKE KNOB	11.55
25	10896	MECHANICAL BRAKE WASHER	1.10
26	1085F	MECHANICAL BRAKE WASHER	1.10
27	1054D	BEARING PULL-OUT STOPPER	1.10
28	105C3	BALL BEARING (3X10X4)	7.15
29	10EYS	BEARING SPACER	2.75
30	105BR	BALL BEARING (5X9X3)	13.75
31	108WK	O-RING SM14	1.65
34	10SRM	ROLLER CLUTCH INNER TUBE	6.05
35	10D54	STAR DRAG PLATE	3.85
36	13VG2	DRAG CLICK SILRATCHET	1.65
37	13UT5	STAR DRAG WASHER	3.85
38	10C0T	DRAG CLICK PIN	2.75
39	10J8A	DRAG CLICK SPRING	1.65
40	10J87	DRAG SPRING HOLDER	1.65
42	1025A	STAR DRAG WASHER	6.05
43	13USS	STOPPER GEAR	6.05
44	10SG7	DRIVE GEAR SHAFT	11.55
45	10JDY	WORM SHAFT GEAR SPRING	1.65
46	10HJG	WORM SHAFT GEAR PINS	1.65
47	101K8	WORM SHAFT GEAR	3.85
48	10S3Y	FIXING BOLT	1.10
49	109T1	DRIVE GEAR SHAFT FIXING PLATE	2.75
50	105BP	BALL BEARING (5X9X3)	13.75
51	1003V	WASHER	2.75
52	105NK	E TYPE STOP RING 2.5	1.10
53	13SH9	LEVEL WIND GUARD	6.05
54	10FJB	LEVEL WINDING RECEIVING PLATE	1.65
55	1003S	WORM SHAFT PIN	2.75
56	10BHQ	WORM SHAFT PIN	2.75
57	108WQ	O-RING	1.65
58	13GH0	LEVEL WINDING ASSEMBLY	11.55
59	10SRL	WORM SHAFT GEAR	3.85
61	10SSP	LEVEL-WIND PIPE	1.65
62	101GT	O-RING	1.65
64	104BC	CLUTCH YOKE SPRING	1.10
66	10LVE	FIXING BOLT	1.10
67	10F3X	CLUTCH CAM PUSH PLATE	3.85
68	10190	WASHER	1.65
69	10SG1	CLUTCH CAM	2.75
70	101M5	CLUTCH CLAW	3.85
71	104CN	CLUTCH CLAW SPRING	1.65
72	10SSV	CLUTCH PLATE	4.95
73	10559	FIXING BOLT	1.65
74	105BT	BALL BEARING (8 X 12 X 3.5)	13.75
75	10SST	BODY A SEAT	3.85
76	10S57	FIXING BOLT	1.65
77	10LCQ	FIXING BOLT	1.10
78	10MPD	FIXING BOLT	1.10
79	13GA7	FRAME ASSEMBLY	50.60
80	10SXB	FIXING BOLT	1.65
81	10SG5	CLUTCH LEVER RECEIVER (B)	1.65
82	101DT	CLUTCH LEVER	6.05
83	10SRK	CLUTCH LEVER HOLDER (A)	1.65
84	13S68	LEVEL-WIND GUIDE	2.75
85	10S42	WASHER	2.75
86	105NC	E TYPE RETAINING RING 2	1.10
87	103LU	FIXING BOLT	1.10
88	10SXA	FIXING BOLT	1.65
90	13GGQ	SPOOL ASSEMBLY	78.65
91	13RN7	B RECEIVING BASE ASSEMBLY	112.20
92	10TBS	FIXING BOLT	1.65
93	10LFN	FIXING BOLT	1.10
94	100MF	WASHER	2.75
95	13FZA	BRAKE DIAL ASSEMBLY	9.35
96	10GQZ	CLICK SPRING	1.10
97	10TA1	SOUND SHILLING	1.65
98	10T4P	WASHER	3.85
99	10B94	BEARING SEAL	1.65
100	100Q2	BEARING STOPPER	2.75
101	10EX5	SPOOL SHAFT CONTACT B	1.10
102	100Q5	SPOOL SHAFT CONTACT C	1.65
103	13RGB	BODY B	6.05
104	13FT4	BODY B ASSEMBLY	168.30
151	10NC0	REEL WRENCH (ACCESSORY)	1.65
203	13JD2	HANDLE ASSEMBLY	67.65
204	13TWZ	MAIN BODY A	22.55
205	10TM8	ROLLER CLUTCH *Cannot be ordered	17.05
206	13UX9	DRIVE GEAR	28.05
207	10ST0	WORM SHAFT	2.75
208	10SGC	PINION GEAR	11.55
209	1046V	CLUTCH YOKE	1.65
210	13UEZ	WASHER	2.20
PUNT	13JRB	INSTRUCTION MANUAL EXPLODED VIEW SET（ACCESSORY)	3.85
STMK	13X13	LOWER WINDING GAUGE (ACCESSORY)	1.65

Description

This is SHIMANO original spool equipped on EXSENCE DC SS series.
You may use as an extra spool with different line strength.




Line Capacity
PE Braided line(No. -m): 1-365, 1.5-255, 2-180
Fluoro(lb-m): 12-130, 14-95, 16-85


Compatibility
20 EXSENCE DC SS
( HG, XG )　
* for both LEFT and RIGHT
