[Avail] Microcast Brake 16SCP (only Avail spool for 17 CHRONARCH MGL, 16 Scorpion 70/71)

Description



This item enables a magnetic brake system by installing on Avail Microcast spools.

As of February 2018, it will be compatible with two models of microcast spools for the 16 Scorpion 70, two types of microcast spools for the 17 Chronarch MGL, etc.

The magnet brake ALD15 is also compatible with these spools, but we found that the overall length of the brake is slightly shorter and unsuitable for adjustment in some situations, so we developed the 16SCP, which is longer than the ALD15.

Although this is a magnetic brake, it does not require a brake unit to be attached to the spool itself, thus reducing the spool's own weight more.


Spec

Material : Polyacetal resin

Weight : 6.2g


Compatibility

Avail Microcast Spool :

・ 16SCP7020RI
・ 16SCP7040RI

・ 17CRNC36RI
・ 17CRNC60RI


Instructions

How to attach the magnet brake

Adjust the magnet brake not to touch the spool when you click the outside dial to 6.
It is natural that SHIMANO’s outside dial is not considered to be matched to Avail’s magnet brake system as SVS infinity is made to be functioned smoothly. Hence, when you adjust the brake dial correctly to 1 or 2, almost no brake is available. But, it is not defective. Adjust the brake function as long as it is available and use it.



Detach the side cover from the reel body and take 3 bolts from the Frame B set inside.




Take the fixing bolt out the dial, then remove the brake dial and brake pipe gear. As the gear tooth is caught in the screw shape cut, further clicking dial is required when it is difficult to remove it.




Avail magnet brake has 2 position of concavities and the point you can not find the gear tooth inside. Set the point you can not find the gear tooth like above photo, put the brake into the frame B set and screw in as far as it will go.




Attach the dial to the front side of the frame B set, click the dial until it goes to outside dial position 4. At this time, set the dial with fixing bolts.




From this point, assemble is only required. Fix the 3 points of the frame B set with fixing bolts.




After completion of assemble, adjust the brake with outside dial position 1.


Adjust the mechanical brake after installing the spool, and loosen a bit from the position which spool does not wobbly from side to side.

After adjusting mechanical brake, click the outside dial to 6. If the brake touch to the spool, loosen the magnet of brake and separate it from the spool. If not, loosen the magnet and close the brake to the spool as possible as you can.
