[Avail] ABU Microcast Spool [AMB5030R-BB] for Ambassadeur 5000 OLD (Ball Bearing Required) (Spool rim level: 3.0mm)
![Photo1: [Avail] ABU Microcast Spool [AMB5030R-BB] for Ambassadeur 5000 OLD (Ball Bearing Required) (Spool rim level: 3.0mm) (1)](https://www.hedgehog-studio.co.jp/phone/data/hedgehog-studio/product/20230207_7d250c.jpg)
Our Selling Price: US$66.00 [Regular Price: US$110.00]
Item Description
Model
Microcast spool for ABU Ambassadeur 5000 Ball Bearing
Microcast Spool AMB5030R-BB (Spool rim level: 3.0mm)
Color
Black
Gunmetal
Red
Silver
Product Description
Reel: ABU Ambassadeur 5000/5000D
Microcast Spool for Ambassadeur 5000 OLD.
Can be installed on old Ambassadeur 5000 and 5000D.
When using line alarms with the 5000D, order Line Alarm Gear Collar (sold separately) together.
The "Bronze Bushing Model" has a spool shaft similar to that of the genuine spool, but a "Ball Bearing Model" is also available with a spool shaft that can be changed to a bearing specification.
*If you use the "Ball Bearing Model", two 10x3x4 bearings are required separately.
The Ambassadeur5000 does not fit the Palming model or the ULTRACAST model.
Please be careful not to make a mistake.い。
Fits reels with spool shafts of the shape shown in the photo.
On the right, the cogwheel is removed.
Remove the cogwheel and check the shape of the part that will be hidden.
Feature
By reducing the weight of the spool and the amount of spooled thread, the overall weight of the spool can be significantly reduced.
It greatly improves the minimum castable lure weight and increases the lure's casting distance at the same weight.
Spec
Basic Specifications
- Material
Spool part: Super duralumin (colored by anodizing)
Shaft part: Stainless steel
- Compatible reels
Ambassadeur 5000/5000D
*Ball bearing specification spools are not compatible with 5000C.
Not available for ULTRACAST model and Palming model.
*If you have any questions, please contact us by e-mail.
- Weight
Spool/Weight/Weight ratio to genuine
Microcast Spool AMB5030R-BB/14.2g/57.0%
Genuine spool Ambassadeur 5000 (4-screw)/24.9g/-
Weight may vary slightly depending on the production lot.
Line Capacity
（Microcast Spool AMB5030R-BB）
12lb φ0.285mm：75m
14lb φ0.310mm：60m
16lb φ0.330mm：45m
The above values are measured with Yamatoyo Tegusu Co., Ltd. nylon line (Versatile Design) wound up to the C surface of the spool.
Installation instructions for using the line alarm function
To use the line alarm function, order the Line Alarm Gear Collar (sold separately) together.
Installation when the line alarm function is not used
If the line alarm function is not used, the installation is as shown above.
White clicker line alarm gear collars are not required.
Attention
Thumbing with the spool rim may cause the anodized aluminum to peel off due to friction.
Thumbing should be done on the line winding surface of the spool.
